ASI8213S-W: Advanced Face Recognition Access Controller

March 24, 2025

In the rapidly evolving landscape of security systems, the integration of advanced technologies such as facial recognition has become essential for efficient access control. The ASI8213S-W Face Recognition Access Controller represents a significant advancement in this field, offering a comprehensive solution that combines cutting-edge technology with user-friendly design. This device is engineered to provide robust security while maintaining ease of use, making it suitable for a wide range of applications from corporate offices to residential complexes.

Product Overview

The DAHUA ASI8213S-W is a standalone access controller equipped with an 8" LCD touchscreen display featuring a resolution of 1280 × 800. It incorporates a 2-MP CMOS dual-lens camera, enabling high-quality image capture essential for accurate facial recognition. The device supports an impressive capacity of 100,000 users, including up to 50 administrators, along with the ability to store 100,000 faces, 500,000 cards, 100,000 passwords, and 300,000 records. This extensive storage capacity makes it ideal for large-scale installations where managing numerous users is a necessity.

Key Features

Multiple Unlock Methods

The DH-ASI8213S-W offers versatile unlock options including face recognition, IC card, password, and QR code. This flexibility allows users to choose the most convenient method based on their preferences or specific situations. Additionally, the device supports scheduled unlock methods and customizable combinations of these methods, providing enhanced security through multi-factor authentication options.

Advanced Facial Recognition

Utilizing deep learning algorithms, the DAHUA DH-ASI8213S-W accurately recognizes over 360 key points on a target's face, ensuring precise identification. The recognition process is swift, with a response time of just 0.2 seconds per person, facilitating smooth and contactless passage. The device can recognize faces from a distance ranging between 0.3 m to 3 m (0.98 ft-9.84 ft) and is suitable for individuals with heights from 0.9 m to 2.4 m (2.95 ft–7.87 ft), making it versatile for various environments.

User Capacity and Management

With support for 100,000 users, 100,000 face images, 500,000 cards, and 100,000 passwords, the ASI8213S-W is designed to handle extensive user databases efficiently. The device allows for detailed user categorization, including normal users, VIPs, patrol staff, guests, and customized user types, enabling tailored access privileges. The capacity to store 300,000 unlock records provides comprehensive audit capabilities, essential for security management.

Connectivity and Compatibility

The ASI8213S-W features robust connectivity options, including RS-485, RS-232, Wiegand, USB 2.0, and a 10 Mbps/100 Mbps Ethernet port. It supports Wi-Fi connectivity with standards IEEE802.11b/g/n, operating in the 2.4 GHz frequency range. This ensures seamless integration with existing network infrastructure and facilitates remote management and updates. The device is compatible with multiple platforms such as DSS Professional, SmartPSS Lite, and DMSS, enhancing its versatility in different security ecosystems.

Environmental Adaptability

Built to withstand challenging environmental conditions, the ASI8213S-W operates within a temperature range of –30 °C to +60 °C (–22 °F to +140 °F) and humidity levels from 0% to 90% (non-condensing). Its IP65 protection rating ensures reliability in both indoor and outdoor settings, making it suitable for diverse installation scenarios.

Technical Specifications

System Components

Main Processor: Embedded Processor
Network Protocol: UDP; TCP; IPv6; IPv4; RTSP; SIP; P2P; RTP
OSDP Protocol: Yes
SDK and API: Yes

Basic Features

Product Type: Standalone
Display Screen: 8" LCD
Screen Type: Capacitive Touchscreen
Screen Resolution: 1280 (V) × 800 (H)
Camera: 1/2.7" 2MP CMOS HD camera with WDR
WDR: 120 dB
Light Compensation: Auto IR
Voice Prompt: Yes
Speaker: Yes
Casing Material: PC

Functional Capabilities

Verification Method: Card, password, face, QR code, and remote
Unlock Mode: Supports various combinations of verification methods
Card Type: IC card
Frequency Range: 13.560 MHz
Period List: 128
Holiday Period: 128
Network Update: Yes
First User Unlock: Yes
Remote Verification: Yes
Restricted List/Trusted List: Yes
Wi-Fi: Yes
Wireless Standard: IEEE802.11b/802.11g/802.11n
Wireless Frequency Range: 2.4 GHz
Max Transmission Power: ≤20 dBm@2400-2483.5 MHz
Wireless Security Encryption: WPA/WPA2; WPA-PSK/WPA2-PSK
Advertisement Playing: Supports graphic advertisement play
Peripheral Card Reader: 1 × RS-485 card reader, 1 × Wiegand card reader
Multi-user Authentication: Yes
Real-time Monitoring: Yes
Multi-factor Authentication: Yes
Capture Function: Yes
Web Configuration: Yes
Auto Registration: Yes

Performance Metrics

IC Card Encryption: Yes
Card Reading Distance: 4 cm–6 cm (1.57"–2.36")
Face Recognition Height Range: 0.9 m–2.4 m (2.95 ft–7.87 ft)
Face Recognition Distance: 0.3 m–3 m (0.98 ft–9.84 ft)
Face Recognition Accuracy: 99.9%
Face Recognition Time: 0.2 s

User Management

User (Card) Type: Normal, VIP, patrol, guest, customized user 1, customized user 2, etc.
Capacity: 100,000 users, 100,000 face images, 500,000 cards, 100,000 passwords, 300,000 records

Ports and Connectivity

RS-485: 1
RS-232: 1
Wiegand: 1 (input and output port)
USB: 1 × USB 2.0 port
Network Port: 1 × 10 Mbps/100 Mbps Ethernet port
Alarm Input: 2 (On/off signal)
Alarm Output: 2 (Relay)
Alarm Linkage: Yes
Exit Button: 1
Door Status Detection: 1
Lock Control: 1

Power and Protection

Power Adapter: Included
Power Supply: 12 VDC, 2 A
Protection: IP65
Power Consumption: ≤24 W

Physical Dimensions

Product Dimensions: 237.4 mm × 122.6 mm × 24.8 mm (9.35" × 4.83" × 0.98")
Packaging Dimensions: 390.0 mm × 320.0 mm × 360.0 mm (15.35" × 12.60" × 14.17") (H × W × D)
Transport Package Dimensions: 299.0 mm × 164.0 mm × 72.0 mm (11.77" × 6.46" × 2.83") (H × W × D)
Operating Environment: Indoor; outdoor
Gross Weight: 1.0 kg (2.20 lb)

Additional Features

Face Mask Detection: Yes
Advertisement Display: Yes
Person Management: Webpage-based management including adding, deleting, and editing persons
Platform Compatibility: Compatible with DSS Professional, SmartPSS Lite, and DMSS

Market Comparison

Competitor Analysis

To better understand the position of the ASI8213S-W in the market, it's essential to compare it with leading competitors such as Hikvision and Honeywell.

Competitor Analysis: Hikvision DS-K1T672E

The Hikvision DS-K1T672E is a notable competitor in the face recognition access control market. Here are its key features:

Display: 7-inch touch screen with bezel-less design
Camera: 2 MP resolution with visible light and infrared lenses
Recognition Distance: 0.3 m to 3 m
Recognition Time: <0.2 seconds per user
Accuracy Rate: ≥99%
Capacity: 50,000 faces, 50,000 cards, 50,000 events
Protocols: Supports Wiegand and RS-485 protocols
Audio: Two-way audio with noise suppression and echo cancellation
Configuration: Via web client
Mask Detection: Forced mask wearing alert and face mask wearing alert
Card Presentation: Presents card on screen for authentication
Platform Compatibility: Hik-ProConnect and HikCentral Professional

Comparative Advantages of ASI8213S-W

Superior Display: The 8" LCD with higher resolution provides better visibility and interaction compared to the DS-K1T672E's 7" display.
Enhanced User Capacity: The ASI8213S-W supports 100,000 users, 500,000 cards, and 300,000 records, significantly more than the DS-K1T672E's 50,000 faces, 50,000 cards, and 50,000 events.
Versatile Unlock Methods: The ASI8213S-W offers more flexible authentication options including QR code recognition and the ability to combine multiple verification methods.
Advanced Connectivity: The ASI8213S-W supports Wi-Fi connectivity in addition to wired network options, providing more deployment flexibility.
Environmental Robustness: With an IP65 rating, the ASI8213S-W is more suitable for outdoor applications compared to the DS-K1T672E.
Platform Compatibility: The ASI8213S-W works with multiple platforms including DSS Professional, SmartPSS Lite, and DMSS, offering more integration options.

Honeywell Face Recognition Terminal

Display: 7" LCD
Camera: 2MP CMOS
User Capacity: 30,000 faces
Recognition Distance: 0.3 m–1.5 m
Recognition Time: 0.6 s
Connectivity: Ethernet
Power Consumption: ≤20 W

Comparative Advantages of ASI8213S-W

Superior Display: The 8" LCD with higher resolution provides better visibility and interaction compared to competitors' 7" displays.
Enhanced Recognition Range: With a recognition distance of up to 3 m, the ASI8213S-W offers greater flexibility in installation and usage scenarios.
Faster Recognition: Achieving recognition in 0.2 seconds, it outperforms competitors in speed, reducing wait times and improving user experience.
Higher User Capacity: Supporting 100,000 users and 500,000 cards, it is more scalable for large organizations.
Advanced Connectivity: Incorporating Wi-Fi and multiple port options, it provides more versatile integration capabilities.
Environmental Robustness: The IP65 rating ensures reliability in various weather conditions, surpassing many competitors in outdoor usability.
Energy Efficiency: With power consumption of ≤24 W, it maintains efficient operation without compromising on performance.

The ASI8213S-W Face Recognition Access Controller stands out as a premier choice in the security industry, offering a perfect blend of advanced technology, user-friendly design, and robust performance. Its comprehensive feature set, including multiple unlock methods, superior facial recognition capabilities, and extensive connectivity options, makes it adaptable to diverse security needs. When compared to leading competitors like Hikvision and Honeywell, the ASI8213S-W demonstrates significant advantages in display quality, recognition speed, user capacity, and environmental adaptability.

For those seeking a reliable and high-performance access control solution, the ASI8213S-W is available for purchase at CCTV-MALL. This authorized distributor ensures genuine products and provides comprehensive support, making it the ideal choice for your security infrastructure needs.
