In today's rapidly evolving security industry, the integration of artificial intelligence (AI) has revolutionized surveillance systems. Two prominent players in this field, Dahua Technology and Hikvision, have been at the forefront of developing AI-driven surveillance solutions. This article aims to provide an in-depth comparison of Dahua NVR616DH-64-XI and Hikvision's DS-9664NXI-S16(LCD), focusing on their AI capabilities, technical specifications, and overall performance.
Dahua NVR616DH-64-XI: A Project-Oriented AI Solution
Launched by Dahua Technology, the NVR616DH-64-XI is part of the WizMind series, a comprehensive portfolio of AI-powered surveillance solutions designed to meet the demands of various industries. This series encompasses a wide range of products, including Internet Protocol Cameras (IPC), Intelligent Video Surveillance Systems (IVSS), Network Video Recorders (NVR), Pan-Tilt-Zoom cameras (PTZ), Hybrid Digital Video Recorders (XVR), Thermal cameras, and software platforms.
AI Capabilities
The NVR616DH-64-XI leverages industry-leading deep learning algorithms to deliver precise, reliable, and comprehensive AI solutions. Its key AI features include:
-
Video Metadata: This technology enables the detection, tracking, and capturing of vehicles, non-motor vehicles, and people, extracting detailed attributes for each category.
-
Smart Sound Detection: It can identify and analyze various audio events, enhancing situational awareness.
-
Intelligent Video Analytics (IVS): This includes perimeter protection, face detection, smart object detection, and people counting, among others.
-
AcuPick: An advanced search technology that utilizes both front-end and back-end intelligence to quickly locate specific targets within massive video data.
Technical Specifications
-
Decoding Formats: Supports Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG.
-
Decoding Capability: Max. 32 × 1080p@30 fps.
-
Network Bandwidth: Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth.
-
AI by Recorder: Supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus.
-
AI by Camera: Supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.
-
Storage: Supports 16 SATA ports, each disk can contain up to 20 TB.
-
RAID: Supports RAID 0/1/5/6/10.
-
Hot Swapping: Yes.
-
LCD Screen: Yes.
-
N+M Cluster: Yes.
-
ISCSI: Yes.
-
Drawer-like Chassis Design: Allows for HDD hot swapping.
-
EPTZ: Yes.
-
One-click Arming & Disarming: Yes.
-
Security Baseline: 2.3.
Hikvision DS-9664NXI-S16(LCD): A High-Performance NVR
Hikvision's DS-9664NXI-S16(LCD) is part of the NXI-S series, designed for high-grade recording and AI capabilities in IP video surveillance applications. This enterprise-level NVR boasts a powerful processor, built-in deep learning modules, and video metadata technology.
AI Capabilities
The DS-9664NXI-S16(LCD) offers a robust set of AI features, including:
-
Facial Recognition: Capable of face picture comparison, human face capture, and face picture search with support for up to 64 face picture libraries.
-
Perimeter Protection: It can filter out false alarms caused by animals, leaves, and other non-threatening entities.
-
Video Structuralization: This feature allows for the structured analysis of video content, making it easier to search and retrieve specific information.
-
AcuSearch: An industry-leading search technology that can quickly locate targets within vast amounts of video data.
Technical Specifications
-
Decoding Formats: H.265+/H.265/H.264+/H.264.
-
Decoding Capability: Up to 32×1080p decoding capacity.
-
Network Bandwidth: Max. 1280Mbps incoming bandwidth, 1024Mbps outgoing bandwidth.
-
AI by NVR: Supports facial recognition, perimeter protection, video structuralization.
-
AI by Camera: Supports facial recognition, perimeter protection, video structuralization, AcuSearch, motion detection 2.0, ANPR, people counting, VCA.
-
Storage: Supports 16 SATA interfaces, 3.5-inch HDD, up to 20 TB capacity for each HDD.
-
RAID: Supports RAID 0, 1, 5, 6, 10.
-
Redundant Power Supply: Yes.
-
HDMI Video Output: Up to 8K resolution.
Comparative Analysis: Dahua NVR616DH-64-XI vs. Hikvision DS-9664NXI-S16(LCD)
AI Features and Performance
| Feature | Dahua NVR616DH-64-XI | Hikvision DS-9664NXI-S16(LCD) |
|---|---|---|
| Face Detection | Supports up to 64 channels | Supports up to 16 channels |
| Face Recognition | Supports up to 40 face databases with 300,000 face images | Supports up to 64 face picture libraries with 300,000 face pictures |
| Perimeter Protection | Supports 32 channels (by recorder) and all channels (by camera) | Supports 8 channels (by NVR) and all channels (by camera) |
| Video Metadata | Supports 8 channels (by recorder) and 64 channels (by camera) | Supports structured analysis for 8 channels (by NVR) and all channels (by camera) |
| ANPR | Supports all channels | Supports ANPR function |
| SMD Plus | Supports 32 channels (by recorder) and all channels (by camera) | Not specified |
| Heat Map | Supports heat map technology | Not specified |
| AcuPick | Supports up to 64 channels | Supports up to 32 channels |
Technical Specifications
| Specification | Dahua NVR616DH-64-XI | Hikvision DS-9664NXI-S16(LCD) |
|---|---|---|
| Decoding Capability | 32 × 1080p@30 fps | 32×1080p |
| Network Bandwidth | 1280 Mbps incoming, 1280 Mbps recording, 1024 Mbps outgoing | 1280Mbps incoming, 1024Mbps outgoing |
| Storage Capacity | 16 SATA ports, up to 20 TB per disk | 16 SATA interfaces, up to 20 TB per disk |
| RAID Support | RAID 0/1/5/6/10 | RAID 0, 1, 5, 6, 10 |
| HDMI Output | 4 HDMI ports, up to 8K resolution | 4 HDMI ports, up to 8K resolution |
| LCD Screen | Yes | Yes |
| Hot Swapping | Yes | Yes |
| Power Supply | 100–240 VAC, 50±2% Hz | 100 to 240 VAC, 50 to 60 Hz, redundant power supply |
| Operating Temperature | –10 °C to +55 °C (14 °F to +131 °F) | -10 to 55°C (14 to 131° F) |
| Weight | 12.83 kg (28.29 lb) | ≤ 12 kg (without HDD, 28.7 lb.) |
Performance in Real-World Scenarios
Both the Dahua NVR616DH-64-XI and Hikvision DS-9664NXI-S16(LCD) are designed for large-scale surveillance applications. However, their performance can vary depending on specific use cases.
-
Large Public Areas: The Dahua NVR616DH-64-XI's superior decoding capability and AI features make it ideal for monitoring large public areas such as supermarkets, schools, industrial parks, and bus stations. Its support for 64 channels of face detection and recognition ensures comprehensive coverage and accurate identification.
-
High-Security Facilities: The Hikvision DS-9664NXI-S16(LCD) is well-suited for high-security facilities where facial recognition and perimeter protection are critical. Its robust AI capabilities and redundant power supply provide reliable performance in environments where security cannot be compromised.
Both Dahua's NVR616DH-64-XI and Hikvision's DS-9664NXI-S16(LCD) are exceptional AI-powered surveillance solutions with advanced features and robust performance. The choice between them depends on specific project requirements, including the scale of surveillance, specific AI functionalities needed, and environmental conditions.
For applications requiring extensive AI capabilities across multiple channels, the Dahua NVR616DH-64-XI is the preferred choice. Its comprehensive AI features, superior decoding capabilities, and flexible storage options make it a versatile solution for a wide range of surveillance needs.
On the other hand, the Hikvision DS-9664NXI-S16(LCD) is an excellent choice for high-security environments where reliability and redundancy are paramount. Its robust AI functionalities, combined with a redundant power supply and high-resolution video output, make it a dependable solution for critical surveillance applications.
In conclusion, both devices represent the cutting edge of AI-powered surveillance technology, offering significant advantages over traditional surveillance systems. The decision should be based on a thorough evaluation of project-specific needs and priorities.
