Dahua Technology, a frontrunner in the global video-centric smart IoT solution and service industry, has taken a significant step forward by upgrading its entry-level IP surveillance system. This upgrade focuses on a series of entry-level IP products, including IPCs, NVRs, switches, and more, enhancing their ease of connection, use, and maintenance. The new system is designed to be highly expandable, open, and compatible, making it an ideal choice for various scenarios.

Key Features of Dahua NVR:

1. Easy Connection:

   • Plug & Play (PnP): Dahua's NVRs come with a user-friendly Plug & Play feature that simplifies the process of setting up an IP monitoring system. When an IPC is connected to the NVR's built-in switch, it automatically initializes, and the camera feed is displayed on the NVR without any complex setup.
   • Automatic Wireless Pairing: The wireless NVRs can automatically pair with wireless IPCs within 120 seconds of starting the system, streamlining operations for quick and efficient deployment.

2. Easy Usage:

   • NVR Channel Management on APP: Dahua's NVRs integrate channel management functions within their COS & DMSS apps, allowing end-users and installers to perform a range of operations such as device search, initialization, channel addition, preview, and drawing directly from their mobile devices.

3. Easy Maintenance:

   • Password Reset through DMSS: Users can easily reset their NVR passwords through the DMSS app after linking their NVR key to their DMSS account.
   • Cloud Update: Devices support over-the-cloud firmware updates, both through the DMSS app and the local interface, ensuring devices are always up-to-date with the latest features and security patches.

Solution and Products: The upgraded Dahua entry-level IP surveillance system offers a comprehensive solution that includes:

• IPCs for video capture
• NVRs for video recording and management
• Desktop PoE Switches for simplified power and data transmission
• Wi-Fi Routers for wireless connectivity
• DMSS/COS Pro apps for device management and monitoring

Highlights:

• Power over Ethernet (PoE): Use PoE switches to power IPCs, eliminating the need for additional power cables.
• Mobile App Support: NVR channel management is supported on mobile apps, allowing for all basic configurations to be completed on one device.
• Live View and Playback: The DMSS app supports live viewing, video playback, and alarm push notifications.
• Maintenance Notifications: COS Pro sends push notifications about maintenance and system failures, enabling timely operator responses.
• Firmware Updates: Support for cloud-based firmware updates ensures devices are always running the latest software.

Application Scenarios: The upgraded Dahua NVR system is suitable for a wide range of applications, including but not limited to retail shops and residential villas, providing a scalable and reliable surveillance solution for small to medium-sized security needs.

DAHUA NVR616DRH-128-XI 128CH 3U 16HDDs WizMind Network Video Recorder

NVR616DRH-128-XI

128CH 3U 16HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.  Max. decoding capability: 32 × 1080p@30 fps.

> Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth.

> Supports AcuPick with up to 64 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports LCD screen, redundant power, N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping.

> Supports EPTZ, One-click Arming & Disarming.

> Security baseline 2.3.

DAHUA NVR616DH-128-XI 128CH 3U 16HDDs WizMind Network Video Recorder

NVR616DH-128-XI

128CH 3U 16HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats. > Max. decoding capability: 32 × 1080p@30 fps. > Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth. > Supports AcuPick with up to 64 channels. > AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus. > AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting. > Supports LCD screen, N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping. > Supports EPTZ, One-click Arming & Disarming. > Security baseline 2.3.

DAHUA NVR616DRH-64-XI 64CH 3U 16HDDs WizMind Network Video Recorder

NVR616DRH-64-XI

64CH 3U 16HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats. > Max. decoding capability: 32 × 1080p@30 fps. > Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth. > Supports AcuPick with up to 64 channels. > AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus. > AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting. > Supports LCD screen, redundant power, N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping. > Supports EPTZ, One-click Arming & Disarming. > Security baseline 2.3.

DAHUA NVR616DH-64-XI 64CH 3U 16HDDs WizMind Network Video Recorder

NVR616DH-64-XI

64CH 3U 16HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats. > Max. decoding capability: 32 × 1080p@30 fps. > Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth. > Supports AcuPick with up to 64 channels. > AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus. > AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting. > Supports LCD screen, N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping. > Supports EPTZ, One-click Arming & Disarming. > Security baseline 2.3.

DAHUA NVR616RH-128-XI 128CH 3U 16HDDs WizMind Network Video Recorder

NVR616RH-128-XI

128CH 3U 16HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats. > Max. decoding capability: 32 × 1080p@30 fps. > Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth. > Supports AcuPick with up to 64 channels. > AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus. > AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting. > Supports redundant power, N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping. > Supports EPTZ, One-click Arming & Disarming. > Security baseline 2.3.

DAHUA NVR616H-128-XI 128CH 3U 16HDDs WizMind Network Video Recorder

NVR616H-128-XI

128CH 3U 16HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats. > Max. decoding capability: 32 × 1080p@30 fps. > Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth. > Supports AcuPick with up to 64 channels. > AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus. > AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting. > Supports N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping. > Supports EPTZ, One-click Arming & Disarming. > Security baseline 2.3.

DAHUA NVR616RH-64-XI 64CH 3U 16HDDs WizMind Network Video Recorder

NVR616RH-64-XI

64CH 3U 16HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats. > Max. decoding capability: 32 × 1080p@30 fps. > Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth. > Supports AcuPick with up to 64 channels. > AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus. > AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting. > Supports redundant power, N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping. > Supports EPTZ, One-click Arming & Disarming. > Security baseline 2.3.

DAHUA NVR616H-64-XI 64CH 3U 16HDDs WizMind Network Video Recorder

NVR616H-64-XI

64CH 3U 16HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats. > Max. decoding capability: 32 × 1080p@30 fps. > Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth. > Supports AcuPick with up to 64 channels. > AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus. > AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting. > Supports N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping. > Supports EPTZ, One-click Arming & Disarming. > Security baseline 2.3.

DAHUA NVR616RH-32-XI 32CH 3U 16HDDs WizMind Network Video Recorder

NVR616RH-32-XI

32CH 3U 16HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats. > Max. decoding capability: 32 × 1080p@30 fps. > Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth. > Supports AcuPick with up to 32 channels. > AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus. > AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting. > Supports redundant power, N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping. > Supports EPTZ, One-click Arming & Disarming. > Security baseline 2.3.

DAHUA NVR616H-32-XI 32CH 3U 16HDDs WizMind Network Video Recorder

NVR616H-32-XI

32CH 3U 16HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats. > Max. decoding capability: 32 × 1080p@30 fps. > Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth. > Supports AcuPick with up to 32 channels. > AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus. > AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting. > Supports N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping. > Supports EPTZ, One-click Arming & Disarming. > Security baseline 2.3.

DAHUA NVR608RH-128-XI 128CH 2U 8HDDs WizMind Network Video Recorder

NVR608RH-128-XI

128CH 2U 8HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps.

> Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth.

> Supports AcuPick with up to 64 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports redundant power, N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping.

> Supports EPTZ, One-click Arming & Disarming.

> Security baseline 2.3.

DAHUA NVR608RH-64-XI 64CH 2U 8HDDs WizMind Network Video Recorder

NVR608RH-64-XI

64CH 2U 8HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps.

> Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth.

> Supports AcuPick with up to 64 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports redundant power, N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping.

> Supports EPTZ, One-click Arming & Disarming.

> Security baseline 2.3.

DAHUA NVR608RH-32-XI 32CH 2U 8HDDs WizMind Network Video Recorder

NVR608RH-32-XI

32CH 2U 8HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps.

> Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth.

> Supports AcuPick with up to 32 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports redundant power, N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping.

> Supports EPTZ, One-click Arming & Disarming.

> Security baseline 2.3.

DAHUA NVR608H-128-XI 128CH 2U 8HDDs WizMind Network Video Recorder

NVR608H-128-XI

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps.

> Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth.

> Supports AcuPick with up to 64 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping.

> Supports EPTZ, One-click Arming & Disarming.

> Security baseline 2.3.

DAHUA NVR608H-64-XI 64CH 2U 8HDDs WizMind Network Video Recorder

NVR608H-64-XI

64CH 2U 8HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps.

> Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth.

> Supports AcuPick with up to 64 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping.

> Supports EPTZ, One-click Arming & Disarming.

> Security baseline 2.3.

DAHUA NVR608H-32-XI 32CH 2U 8HDDs WizMind Network Video Recorder

NVR608H-32-XI

32CH 2U 8HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps.

> Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth.

> Supports AcuPick with up to 32 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping.

> Supports EPTZ, One-click Arming & Disarming.

> Security baseline 2.3.

DAHUA NVR5816H-XI  16CH 2U 8HDDs WizMind Network Video Recorder

NVR5816H-XI

16CH 2U 8HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps or 16 × 4 MP@30 fps.

> Max. 512/512/512 Mbps incoming/recording/outgoing bandwidth.

> Supports IP cameras with a resolution up to 32 MP.

> Supports AcuPick with up to 16 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 20 face databases and 200,000 face images; 8-channel metadata; 16-channel perimeter protection; 16-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports RAID 0/1/5/6/10, N+M cluster, and iSCSI, and has a drawer-like chassis design that allows HDD hot swapping.

> Supports EPTZ, and one-click arming and disarming.

DAHUA NVR5816RH-XI 16CH 2U 8HDDs WizMind Network Video Recorder

NVR5816RH-XI

16CH 2U 8HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps or 16 × 4 MP@30 fps.

> Max. 512/512/512 Mbps incoming/recording/outgoing bandwidth.

> Supports IP cameras with a resolution up to 32 MP.

> Supports AcuPick with up to 16 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 20 face databases and 200,000 face images; 8-channel metadata; 16-channel perimeter protection; 16-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports redundant power, RAID 0/1/5/6/10, N+M cluster, and iSCSI, and has a drawer-like chassis design that allows HDD hot swapping.

> Supports EPTZ, and one-click arming and disarming.

DAHUA NVR5832H-XI 32CH 2U 8HDDs WizMind Network Video Recorder

NVR5832H-XI

32CH 2U 8HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps.

> Max. 512/512/512 Mbps incoming/recording/outgoing bandwidth.

> Supports IP cameras with a resolution up to 32 MP.

> Supports AcuPick with up to 32 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 20 face databases and 200,000 face images; 8-channel metadata; 24-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports RAID 0/1/5/6/10, N+M cluster, and iSCSI, and has a drawer-like chassis design that allows HDD hot swapping.

> Supports EPTZ, and one-click arming and disarming.

DAHUA NVR5832RH-XI 32CH 2U 8HDDs WizMind Network Video Recorder

NVR5832RH-XI

32CH 2U 8HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps.

> Max. 512/512/512 Mbps incoming/recording/outgoing bandwidth.

> Supports IP cameras with a resolution up to 32 MP.

> Supports AcuPick with up to 32 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 20 face databases and 200,000 face images; 8-channel metadata; 24-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports redundant power, RAID 0/1/5/6/10, N+M cluster, and iSCSI, and has a drawer-like chassis design that allows HDD hot swapping.

> Supports EPTZ, and one-click arming and disarming.

DAHUA NVR5864H-XI 64CH 2U 8HDDs WizMind Network Video Recorder

NVR5864H-XI

64CH 2U 8HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps.

> Max. 512/512/512 Mbps incoming/recording/outgoing bandwidth.

> Supports IP cameras with a resolution up to 32 MP.

> Supports AcuPick with up to 36 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 20 face databases and 200,000 face images; 8-channel metadata; 24-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports RAID 0/1/5/6/10, N+M cluster, and iSCSI, and has a drawer-like chassis design that allows HDD hot swapping.

> Supports EPTZ, and one-click arming and disarming.

DAHUA NVR5864RH-XI 64CH 2U 8HDDs WizMind Network Video Recorder

.

NVR5864RH-XI

64CH 2U 8HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps.

> Max. 512/512/512 Mbps incoming/recording/outgoing bandwidth.

> Supports IP cameras with a resolution up to 32 MP.

> Supports AcuPick with up to 36 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 20 face databases and 200,000 face images; 8-channel metadata; 24-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports redundant power, RAID 0/1/5/6/10, N+M cluster, and iSCSI, and has a drawer-like chassis design that allows HDD hot swapping.

> Supports EPTZ, and one-click arming and disarming.

DAHUA NVR5864-XI 64CH 2U 8HDDs WizMind Network Video Recorder

NVR5864-XI

64CH 2U 8HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps

> Max. 384/384/384 Mbps incoming/recording/outgoing bandwidth.

> Supports IP cameras with a resolution up to 32 MP.

> Supports AcuPick with up to 24 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 20 face databases and 200,000 face images; 8-channel metadata; 24-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports N+M cluster, Raid 0/1/5/6/10, ISCSI.

> Supports QuickPick, EPTZ, and one-click arming and disarming.

DAHUA NVR5832-XI  32CH 2U 8HDDs WizMind Network Video Recorder

NVR5832-XI

32CH 2U 8HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps

> Max. 384/384/384 Mbps incoming/recording/outgoing bandwidth.

> Supports IP cameras with a resolution up to 32 MP.

> Supports AcuPick with up to 24 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 20 face databases and 200,000 face images; 8-channel metadata; 24-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports N+M cluster, Raid 0/1/5/6/10, ISCSI.

> Supports QuickPick, EPTZ, and one-click arming and disarming.

DAHUA NVR5432-16P-XI 32CH 1.5U 16POE 4HDDs WizMind Network Video Recorder

NVR5432-16P-XI

32CH 1.5U 16POE 4HDDs WizMind Network Video Recorder

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 32 × 1080p@30 fps

> Max. 512/512/512 Mbps incoming/recording/outgoing bandwidth.

> Supports IP cameras with a resolution up to 32 MP.

> Supports AcuPick with up to 32 channels.

> AI by Recorder supports 8-channel face detection and recognition, up to 20 face databases and 200,000 face images; 8-channel metadata; 24-channel perimeter protection; 32-channel SMD Plus.

> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.

> Supports N+M cluster, ISCSI.

> Supports EPTZ, and one-click arming and disarming.

DAHUA NVR4832-EI 32CH 2U 8HDDs WizSense Network Video Recorder

NVR4832-EI

32CH 2U 8HDDs WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4832-16P-EI 32CH 2U 16PoE 8HDDs WizSense Network Video Recorder

NVR4832-16P-EI

32CH 2U 16PoE 8HDDs WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4816-16P-EI 16CH 2U 16PoE 8HDDs WizSense Network Video Recorder

NVR4816-16P-EI

16CH 2U 16PoE 8HDDs WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4432-EI 32CH 1.5U 4HDDs WizSense Network Video Recorder

NVR4432-EI

32CH 1.5U 4HDDs WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4416-16P-EI 16CH 1.5U 16PoE 4HDDs WizSense Network Video Recorder

NVR4416-16P-EI

16CH 1.5U 16PoE 4HDDs WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4432-16P-EI 32CH 1.5U 16PoE 4HDDs WizSense Network Video Recorder

NVR4432-16P-EI

32CH 1.5U 16PoE 4HDDs WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4416-EI 16CH 1.5U 4HDDs WizSense Network Video Recorder

NVR4416-EI

16CH 1.5U 4HDDs WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4116HS-8P-EI 16CH Compact 1U 8PoE 1HDD WizSense Network Video Recorder

NVR4116HS-8P-EI

16CH Compact 1U 8PoE 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4108HS-8P-EI 8CH Compact 1U 8PoE 1HDD WizSense Network Video Recorder

NVR4108HS-8P-EI

8CH Compact 1U 8PoE 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4108HS-P-EI 8CH Compact 1U 4PoE 1HDD WizSense Network Video Recorder

NVR4108HS-P-EI

8CH Compact 1U 4PoE 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 80 Mbps.

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4104HS-P-EI 4CH Compact 1U 4PoE 1HDD WizSense Network Video Recorder

NVR4104HS-P-EI

4CH Compact 1U 4PoE 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 80 Mbps.

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4116HS-EI 16CH Compact 1U 1HDD WizSense Network Video Recorder

NVR4116HS-EI

16CH Compact 1U 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4108HS-EI 8CH Compact 1U 1HDD WizSense Network Video Recorder

NVR4108HS-EI

8CH Compact 1U 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 80 Mbps.

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4104HS-EI 4CH Compact 1U 1HDD WizSense Network Video Recorder

NVR4104HS-EI

4CH Compact 1U 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 80 Mbps.

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4116-8P-EI 16CH Smart 1U 8PoE 1HDD WizSense Network Video Recorder

NVR4116-8P-EI

16CH Smart 1U 8PoE 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4108-8P-EI 8CH Smart 1U 8PoE 1HDD WizSense Network Video Recorder

NVR4108-8P-EI

8CH Smart 1U 8PoE 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4108-P-EI 8CH Smart 1U 4PoE 1HDD WizSense Network Video Recorder

NVR4108-P-EI

8CH Smart 1U 4PoE 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 80 Mbps.

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4104-P-EI 4CH Smart 1U 4PoE 1HDD WizSense Network Video Recorder

NVR4104-P-EI

4CH Smart 1U 4PoE 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 80 Mbps.

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4104-P-EI 4CH Smart 1U 4PoE 1HDD WizSense Network Video Recorder

NVR4104-P-EI

4CH Smart 1U 4PoE 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 80 Mbps.

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4116-EI 16CH Smart 1U 1HDD WizSense Network Video Recorder

NVR4116-EI

16CH Smart 1U 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4108-EI 8CH Smart 1U 1HDD WizSense Network Video Recorder

NVR4108-EI

8CH Smart 1U 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 80 Mbps.

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR4104-EI 4CH Smart 1U 1HDD WizSense Network Video Recorder

NVR4104-EI

4CH Smart 1U 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.

> Access, storage or forwarding at 80 Mbps.

> Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.

> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.

> AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.

> Connected to the third-party network cameras.

> Security baseline 2.3.

DAHUA NVR2216-16P-I2 16 Channel 1U 16PoE 2HDDs WizSense Network Video Recorder

NVR2216-16P-I2

16 Channel 1U 16PoE 2HDDs WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format

> Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding

> 1-channel face detection and recognition (AI by NVR); 1-channel perimeter protection (AI by NVR); up to 10 face databases and 5,000 face images; 4-channel SMD Plus (AI by NVR);

> AI by camera: Face detection and recognition, perimeter protection, and SMD Plus

> Connected to the third-party network cameras

> Security baseline 2.1

DAHUA NVR2208-8P-I2 8 Channel 1U 8PoE 2HDDs WizSense Network Video Recorder

NVR2208-8P-I2

8 Channel 1U 8PoE 2HDDs WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format

> Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding

> 1-channel face detection and recognition (AI by NVR); 1-channel perimeter protection (AI by NVR); up to 10 face databases and 5,000 face images; 4-channel SMD Plus (AI by NVR);

> AI by camera: Face detection and recognition, perimeter protection, and SMD Plus

> Connected to the third-party network cameras

> Security baseline 2.1

DAHUA NVR2204-P-I2 4 Channel 1U 4PoE 2HDDs WizSense Network Video Recorder

NVR2204-P-I2

4 Channel 1U 4PoE 2HDDs WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format

> Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding

> 1-channel face detection and recognition (AI by NVR); 1-channel perimeter protection (AI by NVR); up to 10 face databases and 5,000 face images; 4-channel SMD Plus (AI by NVR);

> AI by camera: Face detection and recognition, perimeter protection, and SMD Plus

> Connected to the third-party network cameras

> Security baseline 2.1

DAHUA NVR2216-I2 16 Channel 1U 2HDDs WizSense Network Video Recorder

NVR2216-I2

16 Channel 1U 2HDDs WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format

> Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding

> 1-channel face detection and recognition (AI by NVR); 1-channel perimeter protection (AI by NVR); up to 10 face databases and 5,000 face images; 4-channel SMD Plus (AI by NVR);

> AI by camera: Face detection and recognition, perimeter protection, and SMD Plus

> Connected to the third-party network cameras

> Security baseline 2.1

DAHUA NVR2208-I2 8 Channel 1U 2HDDs WizSense Network Video Recorder

NVR2208-I2

8 Channel 1U 2HDDs WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format

> Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding

> 1-channel face detection and recognition (AI by NVR); 1-channel perimeter protection (AI by NVR); up to 10 face databases and 5,000 face images; 4-channel SMD Plus (AI by NVR);

> AI by camera: Face detection and recognition, perimeter protection, and SMD Plus

> Connected to the third-party network cameras

> Security baseline 2.1

DAHUA NVR2204-I2 4 Channel 1U 2HDDs WizSense Network Video Recorder

NVR2204-I2

4 Channel 1U 2HDDs WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format

> Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding

> 1-channel face detection and recognition (AI by NVR); 1-channel perimeter protection (AI by NVR); up to 10 face databases and 5,000 face images; 4-channel SMD Plus (AI by NVR);

> AI by camera: Face detection and recognition, perimeter protection, and SMD Plus

> Connected to the third-party network cameras

> Security baseline 2.1

DAHUA NVR2108HS-8P-I2 8 Channel Compact 1U 8PoE 1HDD WizSense Network Video Recorder

NVR2108HS-8P-I2

8 Channel Compact 1U 8PoE 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format

> Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding

> 1-channel face detection and recognition (AI by NVR); 1-channel perimeter protection (AI by NVR); up to 10 face databases and 5,000 face images; 4-channel SMD Plus (AI by NVR);

> AI by camera: Face detection and recognition, perimeter protection, and SMD Plus

> Connected to the third-party network cameras

> Security baseline 2.1

DAHUA NVR2104HS-P-I2 4 Channel Compact 1U 4PoE 1HDD WizSense Network Video Recorder

NVR2104HS-P-I2

4 Channel Compact 1U 4PoE 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format

> Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding

> 1-channel face detection and recognition (AI by NVR); 1-channel perimeter protection (AI by NVR); up to 10 face databases and 5,000 face images; 4-channel SMD Plus (AI by NVR);

> AI by camera: Face detection and recognition, perimeter protection, and SMD Plus

> Connected to the third-party network cameras

> Security baseline 2.1

DAHUA NVR2116HS-I2 16 Channel Compact 1U 1HDD WizSense Network Video Recorder

NVR2116HS-I2

16 Channel Compact 1U 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format

> Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding

> 1-channel face detection and recognition (AI by NVR); 1-channel perimeter protection (AI by NVR); up to 10 face databases and 5,000 face images; 4-channel SMD Plus (AI by NVR);

> AI by camera: Face detection and recognition, perimeter protection, and SMD Plus

> Connected to the third-party network cameras

> Security baseline 2.1

DAHUA NVR2108HS-I2 8 Channel Compact 1U 1HDD WizSense Network Video Recorder

NVR2108HS-I2

8 Channel Compact 1U 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format

> Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding

> 1-channel face detection and recognition (AI by NVR); 1-channel perimeter protection (AI by NVR); up to 10 face databases and 5,000 face images; 4-channel SMD Plus (AI by NVR)

> AI by camera: Face detection and recognition, perimeter protection, and SMD Plus

> Connected to the third-party network cameras

> Security baseline 2.1

DAHUA NVR2104HS-I2 4 Channel Compact 1U 1HDD WizSense Network Video Recorder

NVR2104HS-I2

4 Channel Compact 1U 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format

> Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding

> 1-channel face detection and recognition (AI by NVR); 1-channel perimeter protection (AI by NVR); up to 10 face databases and 5,000 face images; 4-channel SMD Plus (AI by NVR);

> AI by camera: Face detection and recognition, perimeter protection, and SMD Plus

> Connected to the third-party network cameras

> Security baseline 2.1

DAHUA NVR2108-8P-I2 8 Channel Smart 1U 8PoE 1HDD WizSense Network Video Recorder

NVR2108-8P-I2

8 Channel Smart 1U 8PoE 1HDD WizSense Network Video Recorder

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format

> Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive decoding

> 1-channel face detection and recognition (AI by NVR); 1-channel perimeter protection (AI by NVR); up to 10 face databases and 5,000 face images; 4-channel SMD Plus (AI by NVR);

> AI by camera: Face detection and recognition, perimeter protection, and SMD Plus

> Connected to the third-party network cameras

> Security baseline 2.1
