IVS-TB8000-xE-GU2
Intelligent Video Analysis Server for Traffic Event Detection
> Adopts Dahua video cloud architecture and supports dynamic adjustment of computing resources for greater precision and control.
> Automatic detection of lane lines and key points of vehicles.
> Supports the global detection application of PTZ Camera scenes.
> Supports one-click deployment of all-in-one machines for small-scale scenarios and simple demonstrations, and supports distributed cluster deployment for large-scale scenarios.
Product Data
System |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Main Processor |
Two Intel Xeon extensible processors, 10 C/20 T for each one |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Intelligent Card |
2–6 AIX3200 intelligent analysis cards |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System |
CentOS Linux release 7.4.1708 (Core) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM |
Four 8 GB DDR4 memory, maximum 24 slots |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Hard Drive |
Two 3.5'' 4 TB disk which can be extended to 32TB (each disk is 4TB), with up to 8 slots |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Traffic Event Detection |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multi-rules Application |
Multiple rules can take effect simultaneously |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Detection Area and Exclusion Area Setting |
Supports detection zone and exclusion zone for the server. The server only triggers alarms for events that occur in the detection zone or outside the exclusion zone. Supports up to 1 detection zone and 10 exclusion zones |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Real-time Display |
Displays detection zone rules and the target tracking box in live view. The rule and target tracking boxes flash on screen when an alarm is triggered |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Parking Detection |
1. Detects an event when a vehicle moves and then stops, and the stop time exceeds the defined value |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pedestrian Detection |
1. Detects an event when a pedestrian walks onto the vehicle lane or into an area where pedestrians are prohibited from entering and the duration exceeds the defined value |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Non-motor Vehicle Detection |
1. Detects battery-powered two-wheelers and tricycles |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Traffic Jam Detection |
1. Detects an event when a lane is congested and the duration exceeds the defined value |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Traffic Flow Statistics |
1. Displays traffic flow statistics in the following order: Lane > traffic flow > small vehicles > medium-sized vehicles > large vehicles > average speed > time occupancy rate > space occupancy rate > spacing > time interval > queuing length |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Visibility Detection |
1. Supports detecting road agglomerate fog |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Littering Detection |
1. Detects an event when an object is littered by a person in a vehicle or a pedestrian disturbs traffic and the duration exceeds the defined value |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Area Intrusion Detection |
1. Detects an event when a motor vehicle enter the detection area |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illegal Lane Change Detection |
1. Detects an event when a vehicle crosses the lane line (yellow or white solid line) and the duration exceeds the defined value |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wrong-way Driving Detection |
1. Detects an event when a vehicle is moving opposite to the specified direction of the traffic and the duration exceeds the defined value. This is to prevent drivers from crossing lanes while driving. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Reversing Detection |
1. Detects events that a vehicle moves wrong way and reverse at a highway intersection |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Construction Detection |
1. Detects construction signs that are in an area for longer than the defined value |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Roadblock Detection |
1. Detects roadblocks that are in an area for longer than the defined value |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Accident Detection |
Detects traffic accidents in an area |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Fire Detection |
1. Detects when a fire breaks out in an area and the duration exceeds the defined value |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smoke Detection |
1. Detects when smog appears in an area and the duration exceeds the defined value |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Crossing Solid Line Detection |
1. Detects when a vehicle crosses the lane line |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Overspeed Detection |
1. Detects when the vehicle speed is higher than the defined value and the vehicle time exceeds the defined value |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Underspeed Detection |
1. Detects when the driving speed is lower than the defined value and the vehicle time exceeds the defined value |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Plate Number Recognition |
Supports ANPR for parking, illegal lane change, crossing the solid yellow line, wrong-way driving, and area intrusion. It is recommended that the license plate width is more than 80 pixels |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Report Generation and Export |
Exports alarm information in Excel form, including device, device IP, channel name, event time, event name, event type, lane, license plate number, speed and more |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Search |
Supports searching for alarm information according to multiple options, such as device, channel, event type, capture time and more |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Traffic Event Detection Application Scenes |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scene Attribute |
Widely used in traffic management, road operations and maintenance scenarios such as expressways, urban expressways, viaducts, tunnels, and cross-sea bridges |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Camera Installation |
Front installation (recommended) and side installation |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Camera Installation Height |
6–12 meters recommended, two or three lanes can be captured |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Camera installation Angle |
Recommended pitch angle is between 10°–15°, covering about 50 m–100 m (164.04 ft–328.08 ft) and lane inclination angle < 30° when side-mounted |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Traffic Event Detection Performance |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Resolution |
1080p or higher |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Analysis Capability |
xE: E refers to intelligent analysis card, and x refers to the number of the card. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Traffic Event Detection Type |
Includes parking, pedestrian on vehicle lane, non-motor vehicle, traffic jam, traffic flow statistics, littering, area intrusion, illegal lane change, wrong-way driving, reversing, construction, roadblock, traffic accident, agglomerate fog, smoke, fire, crossing solid line, overspeed and underspeed detection |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Traffic Parameters |
Traffic flow, average speed, time occupancy rate, space occupation rate, space headway, time headway and queue length |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Parking Detection |
According to test data (1080P access), the detection rate is 90%, and the effective rate is 90%. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pedestrian Detection |
According to test data (1080P access), the detection rate is 90%, and the effective rate is 90%. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Non-motor Vehicle Detection |
According to test data (1080P access), the detection rate is 90%, and the effective rate is 90%. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Traffic Jam Detection |
According to test data (1080P access), the detection rate is 90%, and the effective rate is 90%. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Traffic Flow Statistics |
According to test data (1080P access), the traffic accuracy rate is over 90%. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Visibility Detection |
Subject to actual test |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Littering Detection |
According to test data (1080P access), the detection rate is 80%, and the effective rate is 80%. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Area Intrusion Detection |
According to test data (1080P access), the detection rate is 90%, and the effective rate is 90%. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illegal Lane Change Detection |
According to test data (1080P access), the detection rate is 90%, and the effective rate is 90%. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wrong-way Detection |
According to test data (1080P access), the detection rate is 90%, and the effective rate is 90%. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Reversing Detection |
According to test data (1080P access), the detection rate is 90%, and the effective rate is 90%. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Construction Detection |
According to test data (1080P access), the detection rate is 90%, and the effective rate is 80%. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Roadblock Detection |
According to test data (1080P access), the detection rate is 90%, and the effective rate is 90%. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Traffic Accident Detection |
Subject to actual test |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Fire Detection |
Subject to actual test |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smoke Detection |
Subject to actual test |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Line Crossing Detection |
According to test data (1080P access), the detection rate is 90%, and the effective rate is 90%. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Overspeed Detection |
Subject to actual test |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Underspeed Detection |
Subject to actual test |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
2 × 10,000/1,000 Mbps gigabit Ethernet ports |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
USB |
2 front USB3.0 ports and 3 rear USB3.0 ports |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
VGA |
2 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DVI |
1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PCIe |
8 × standard PCI e |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Other Port |
1 RJ-45 management network port |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply Mode |
100 V-127 V/200 V-240 V~, 50 Hz/60 Hz, 10 A/5 A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Redundancy |
Dual power redundancy |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
≤ 800 W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature |
+10 °C to +35 °C (+50 °F to +95 °F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity |
35%–80% (RH), the maximum relative humidity during operation is 90% RH (+40 °C). |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Humidity |
20%–93% (RH) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
35.0 kg (77.16 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
27.5 kg (60.62 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions |
87.0 mm × 438.0 mm × 735.0 mm (3.43" × 17.24" × 28.94" ) (H × W × D) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packaging Dimensions |
273.0 mm × 754.0 mm × 1069.0 mm (10.75" × 29.68" × 42.08'') (H × W × D) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Installation |
Standard 19" rack installation with guide rail |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mean Time Between Failures |
69.6 years |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification |
CCC: 2019010911224727 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Filter |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Type |
All-in-one server integrating software and hardware |
Type |
Model |
Description |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dahua 2U Intelligent Video Analysis Server for Traffic Event Detection |
DHI-IVS-TB8000-2E-GU2 |
Dahua 2U Intelligent Video Analysis Server for Traffic Event Detection |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DHI-IVS-TB8000-3E-GU2 |
Dahua 2U Intelligent Video Analysis Server for Traffic Event Detection |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DHI-IVS-TB8000-4E-GU2 |
Dahua 2U Intelligent Video Analysis Server for Traffic Event Detection |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DHI-IVS-TB8000-5E-GU2 |
Dahua 2U Intelligent Video Analysis Server for Traffic Event Detection |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DHI-IVS-TB8000-6E-GU2 |
Dahua 2U Intelligent Video Analysis Server for Traffic Event Detection |
