How to Set Up Dahua IVS (Tripwire & Intrusion)
Complete Web 5.0 Guide (With Official Page & Figure References)

Intelligent Video Surveillance, commonly known as IVS, is one of the most powerful features available on modern Dahua AI IP cameras. Unlike basic motion detection, which triggers alerts from any movement — including trees blowing in the wind, rain, insects, or small animals — Dahua IVS uses deep-learning algorithms to distinguish between people, vehicles, and other moving objects. This drastically reduces false alarms while ensuring real threats are never missed.

The two most widely used IVS rules are Tripwire (virtual line crossing detection) and Intrusion (unauthorized area entry). Together, they form the foundation of professional perimeter security for homes, businesses, warehouses, parking lots, construction sites, and government facilities.

In this detailed, step-by-step guide, we will show you how to fully configure Dahua IVS using the Web 5.0 interface, including rule creation, direction control, target filtering, sensitivity adjustment, arming schedules, and alarm linkage. Every section includes official manual page numbers and figure names so you can easily insert accurate screenshots into your blog, technical documentation, or training materials.

This guide applies to all Dahua AI-enabled turret, dome, bullet, and PTZ cameras running Web 5.0 firmware.

Why IVS Is Superior to Basic Motion Detection

Before we begin setup, it’s important to understand why IVS is the preferred choice for professional security:

• Filters out non-threats: Ignores leaves, rain, animals, and shadows.
• Detects direction: Triggers only when someone crosses a line in a specific direction.
• Defines perimeters: Creates protected zones that alert when breached.
• Saves storage space: Records only when real events occur.
• Reduces alert fatigue: Sends meaningful notifications instead of endless false alarms.
• Supports automation: Links to sirens, lights, PTZ cameras, speakers, and access control systems.

Prerequisites

To use IVS on your Dahua camera, ensure the following:

• Your camera supports AI/IVS functions (check model specifications).
• The camera is updated to the latest official firmware.
• You have admin access to the Web 5.0 interface.
• The camera is connected to a stable wired network.
• An SD card or NVR is available for event recording (optional but recommended).

Full IVS Setup Step-by-Step

Main IVS Configuration Page

This is the control center where all rules are added, edited, deleted, and managed. You can create up to 5–10 IVS rules depending on your camera model.

Part 1: How to Set Up Tripwire (Line Crossing Detection)

Tripwire creates a virtual line across your camera view. The camera triggers an alarm when a person or vehicle crosses the line in a direction you specify.

Common uses:

• Perimeter fence monitoring
• Driveway entry/exit
• Door and gate monitoring
• Restricted area boundary control

Step 1: Enable IVS and Add a Tripwire Rule

• Go to the IVS main page (AI → Smart Plan → IVS).
• Check the box labeled Enable to activate IVS.
• Click Add to create a new rule.
• From the dropdown menu, set Rule Type to Tripwire.

Step 2: Draw the Tripwire Line

• Click the Draw Rule (pencil) icon.
• In the live preview window, left-click to set the starting point of your line.
• Move your mouse and left-click again to set the endpoint.
• Right-click to confirm the line.
• You can draw straight lines at any angle — horizontal, vertical, or diagonal.

Step 3: Set Crossing Direction

Choose the direction that triggers the alarm:

• A→B: Only crossing from A to B
• B→A: Only crossing from B to A
• AB: Bi-directional crossing

For example, set A→B to alert only when someone enters your property, not when they leave.

Step 4: Target Filtering (Critical to Reduce False Alerts)

Under Target Filter, enable:

• Human
• Vehicle

Disable all other objects unless required. This ensures the camera ignores pets, birds, and moving foliage.

You can also set Minimum Target Size and Maximum Target Size to ignore objects that are too small or too large.

Step 5: Set Arming Period (Schedule)

Set the times when the Tripwire rule is active.

• Default: 24 Hours / All Days
• You can customize schedules for: Business hours, Nighttime only, Weekdays / weekends

Step 6: Alarm Linkage (What Happens When Triggered)

Under Alarm Linkage, select the actions the camera performs:

• Record: Start event recording
• Snapshot: Take a picture
• Alarm Out: Trigger external siren or light
• PTZ: Call preset on PTZ camera
• Email: Send alert email
• Push: Send phone notification
• Audio Warning: Trigger speaker alarm

Step 7: Save the Rule

Click Apply to save your Tripwire rule.

Part 2: How to Set Up Intrusion (Zone Breach Detection)

Intrusion detection creates a virtual polygon zone that triggers an alarm when a person or vehicle enters, exits, or appears inside the area.

Common uses:

• Roof monitoring
• Backyard security
• Equipment room protection
• Parking lot perimeter
• Construction site safety

Step 1: Add an Intrusion Rule

• On the IVS main page, click Add.
• Set Rule Type to Intrusion.

Page: Page 86

Figure Name: Figure 6–69 Add Intrusion Rule

Step 2: Draw the Intrusion Zone

• Click Draw Rule.
• Left-click to place corner points to form a polygon shape.
• Connect the last point back to the first to close the zone.
• Right-click to confirm.
• You can create any shape: square, rectangle, circle, or irregular polygon.

Step 3: Configure Intrusion Parameters

Action:

• Enter: Alert when entering the zone
• Exit: Alert when leaving
• Enter & Exit: Both directions

Sensitivity: 1–6 (higher = more sensitive)

Duration: How long an object must stay inside to trigger (0–100 seconds)

For high-security areas, set Duration = 0 for instant alerts.

Page: Page 87

Figure Name: Figure 6–71 Intrusion Parameters

Step 4: Target Filter & Alarm Linkage

Just like Tripwire, enable Human and Vehicle filtering.

Set your desired alarm linkages: recording, snapshot, email, siren, etc.

Step 5: Save the Intrusion Rule

Click Apply to activate the zone.

Part 3: Advanced IVS Settings (For All Rules)

Anti-Dither Configuration

Anti-Dither prevents repeat alarms from the same event.

Recommended value: 10–30 seconds

Rule Copy

You can copy rules to different times or days without re-drawing zones.

Part 4: Test Your IVS Rules

After setup, test each rule to confirm functionality:

• Walk across the Tripwire line.
• Step inside the Intrusion zone.

Verify:

• Red bounding box appears on the live view
• Recording starts
• Snapshots are saved
• Email/push alerts are sent

Common IVS Issues & Solutions

Issue 1: IVS does not trigger

• Enable IVS in Smart Plan
• Lower sensitivity
• Check target filter (don’t filter out all objects)
• Update firmware

Issue 2: Too many false alarms

• Increase minimum target size
• Disable non-human/non-vehicle targets
• Reduce sensitivity
• Redraw zones away from trees or reflective surfaces

Issue 3: No recording when IVS triggers

• Enable Record in Alarm Linkage
• Set Record Schedule to Event mode
• Insert SD card or connect to NVR

Issue 4: Rules disappear after reboot

• Backup configuration
• Upgrade firmware
• Factory reset and reconfigure

Conclusion

Dahua IVS (Tripwire & Intrusion) provides professional-grade perimeter security with minimal false alerts. By correctly configuring rules, directions, target filters, schedules, and linkages, you can build a highly reliable security system that works 24/7 without constant supervision.

Whether you’re a homeowner, installer, or business owner, mastering IVS will help you maximize the performance of your Dahua surveillance system.
