Dahua IPC-HDBW5259E1-Z5E-IL 2MP 5x Zoom Smart Dual Light Dome Camera, IK10 Vandal-proof WizMind
Regular price
$10,000.00
Couldn't load pickup availability
Our standard leading time is estimated to be 30 working days, even if it is shown as in stock, please confirm this lead time before purchasing.
Do you have any question about the Products?Contact us now via sales@cctv-mall.com.
 |
 |
Ask Our Experts
|
Please note the following important details when ordering surveillance products from CCTV-MALL: |
Quality Certifications: |
Dahua IPC-HDBW5259E1-Z5E-IL 2MP Smart Dual Light 7 mm–35 mm 5x Zoom Vandal-proof Dome WizMind Network Camera
Key Highlights
- Xinghan Vision Models: Revolutionary upgrade in target detection and imaging. Extends target detection range while drastically slicing false alarm rates through self-learning AI blocks.
- 5x Optical Telephoto Zoom: Powerful 7 mm–35 mm motorized vari-focal lens with autofocus for precision remote field of view customization.
- Ultra-Long Range Smart Dual Light: Features 4 multi-core illuminators delivering up to 120 m (393.70 ft) IR and 80 m (262.47 ft) Warm Light with intelligent auto-switching.
- Built-in Mic & Audio Security: Implements a built-in Mic for clear real-time audio capture. Offers 11 built-in sound alarms and supports up to 10 custom voice sound uploads.
- Vandal-Proof Armor Protection: All-metal casing heavily hardened with IP67 weatherproof and IK10 vandal-proof ratings against catastrophic impacts.
- Advanced Intelligence Suite: Powered by WizMind, supporting AcuPick deep learning target matching, SMD 4.0, Face Detection, EIS (Electronic Image Stabilization), and Video Metadata extraction.
Camera
| Image Sensor | 1/2.7" CMOS |
|---|---|
| Max. Resolution | 1920 (H) × 1080 (V) |
| ROM / RAM | 4 GB / 2 GB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.0007 lux @ F1.6 (Color, 30 IRE) 0.0004 lux @ F1.6 (B/W, 30 IRE) 0 lux (Illuminator on) |
| S/N Ratio | > 56 dB |
| Illumination Distance | IR: Up to 120 m (393.70 ft) Warm light: Up to 80 m (262.47 ft) |
| Illuminator Control / Number | Auto; Manual; Zoomprio | 4 (Multi-core IR + warm light) |
| Angle Adjustment | Pan: 0°–355°; Tilt: 0°–80°; Rotation: 0°–355° |
Lens (5x Optical Zoom)
| Lens Type / Mount | Motorized vari-focal | Module | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Focal Length | 7 mm–35 mm | |||||||||||||||
| Max. Aperture / Iris | F1.6 | Auto Iris | |||||||||||||||
| Field of View (H/V/D) | H: 30°–12°; V: 16°–6°; D: 35°–13° | |||||||||||||||
| Close Focus Distance | W: 1.5 m (4.92 ft) | T: 3 m (9.84 ft) | |||||||||||||||
| DORI Distance |
|
Intelligence & AI
| IVS (Perimeter Protection) | Intrusion, tripwire, fast moving (supports accurate detection and classification of human, vehicle, and animal targets); loitering detection, people gathering, parking detection, stay detection. Offers Perimeter Protection Large-Scale AI Models for extended target ranges and self-learning false alarm filters. |
|---|---|
| SMD / AcuPick | SMD 4.0 | AcuPick Deep learning algorithms (works with back-end devices to accurately match targets including motor vehicles, people, and animals across live and recorded video feeds). |
| Face Detection | Face detection, snapshot, snapshot optimization, optimal face snapshot upload, face enhancement, face exposure. Extracts 6 attributes and 8 expressions. Snapshot strategies include real-time, quality priority, and optimization snapshot. |
| People Counting & Heat Map | Tripwire people counting (day/week/month/year reports). Area counting and queue management (day/week/month reports). Supports up to 4 configurable rules. Heat Map supported. |
| Video Metadata | Detection of motor vehicle, non-motor vehicle, face, and human body. Attributes extraction: extracts 6 attributes for motor vehicles, 6 for non-motor vehicles, 6 for faces, and 8 for human bodies. |
| Smart Search | Works smoothly with Smart NVR to perform refined intelligent searches, event extraction, and event video merging. |
Video
| Video Compression / AI Coding | H.265; H.264; H.264H; H.264B; MJPEG (sub stream only) | AI H.265; AI H.264 (Smart H.265+/Smart H.264+) |
|---|---|
| Video Frame Rate | Main stream: 1920 × 1080 @ (1 fps–25/30 fps); Supports 4 streams. |
| WDR / SSA / Noise Reduction | 120 dB True WDR | Scene Self-adaptation (SSA) Supported | 3D NR |
| Image Stabilization | EIS (Electronic Image Stabilization) |
| Image Optimization | BLC, HLC, ROI (4 areas), Smart Illumination, Smart Dual Light, Defog, Mirror, LDC. |
| Image Rotation | 0°/90°/180°/270° (90°/270° supported with 4M resolution and lower) |
| Privacy Masking | 4 mosaics or 8 color blocks |
Audio & Alarm
| Audio Hardware | Built-in Microphone | 1-ch Input (RCA port), 1-ch Output (RCA port) |
|---|---|
| Audio Compression | G.711a; G.711Mu; PCM; G.726; G.723 |
| Sound Warning | Offers 11 sound alarms and supports importing 10 custom sound alarms (Volume: 0–100, play times: 1–10). |
| Alarm Ports | 2-ch Input (wet contact, 5 mA 3–5 VDC) | 1-ch Output (wet contact, 300 mA 12 VDC) |
| Alarm Events | Motion detection, video tampering, defocus detection, SD card events, network disconnection, illegal access, perimeter triggers, SMD, face detection, metadata, etc. |
Network & Ports
| Network Port / Protocols | RJ-45 (10/100 Enhancement Base-T) | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTSP; SMTP; FTP; SFTP; DHCP; NTP; P2P etc. |
|---|---|
| Interoperability / Browser | ONVIF (Profile S & Profile G & Profile T & Profile M); CGI | IE 11+, Chrome 102+, Firefox 88+ |
| Storage Options | FTP; SFTP; Micro SD card (supports max. 1 TB); NAS |
| Cybersecurity | Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; X.509 certification; HTTPS; 802.1x; Trusted boot/execution/upgrade. |
Power & Environment
| Power Supply / ePoE | 12 VDC (±30%); PoE+ (802.3at) | ePoE supported |
|---|---|
| Dual Power Backup | Supported (System continues to work without restarting when one of the power lines is disconnected) |
| Power Consumption | Basic: 3.7 W (12 VDC); 5 W (PoE) Max. (IR on + WDR + intelligence on + light active deterrence): 12.9 W (12 VDC); 16.1 W (PoE) |
| Operating Conditions | –40 °C to +60 °C (–40 °F to +140 °F) | Humidity ≤95% (RH), non-condensing |
| Protection Rating | IP67 Weatherproof | IK10 Vandal-proof |
Structure
| Casing Material | Metal |
|---|---|
| Product Dimensions | 118.0 mm × Φ159.0 mm (4.65" × Φ6.26") |
| Weight | Net Weight: 1.16 kg (2.56 lb) | Gross Weight: 1.36 kg (3.00 lb) |
