Camera Image Sensor Fixed Lens: 1/1.8" CMOS PT Lens: 1/2.8" CMOS Pixel Fixed Lens: 4 MP PT Lens: 2 MP Max. Resolution Fixed Lens: 2688 (H) × 1520 (V) PT Lens: 1920 (H) × 1080 (V) ROM 256 MB RAM 512 MB Electronic Shutter Speed 1 s–1/100,000 s Scanning System Progressive Min. Illumination Fixed Lens: 0.0005 lux@F1.0 (Color, 30 IRE) 0 lux (Illuminator on) PT Lens: 0.0005 lux@F1.0(Color, 30 IRE) 0 lux (Illuminator on) Illumination Distance Fixed Lens: 2.8 mm PT Lens: 3.6 mm; 8.4 mm: Fixed Lens: 30 m (98.43 ft) (Warm light) PT Lens: 50 m (164.04 ft) (Warm light) Illuminator On/Off Control Fixed Lens: Manual; Auto; Off PT Lens: Manual; Auto; Off Illuminator Number Fixed Lens: 4 (Warm light) PT Lens: 4 (Warm light) Lens Focal Length Fixed Lens: 2.8 mm PT Lens: 3.6 mm; 8.4 mm Max. Aperture Fixed Lens: F1.0 PT Lens: 3.6 mm: F1.0; 8.4 mm: F1.0 Field of View Fixed Lens: 2.8 mm PT Lens: 3.6 mm; 8.4 mm: Fixed Lens: H:112 °; V: 60°; D: 134° PT Lens: H: 81.5° – 15.1°; V: 44.3° – 8.4°; D: 96.3° – 17.88° Hybrid Zoom 6× Close Focus Distance Fixed Lens: 2.8 mm PT Lens: 3.6 mm; 8.4 mm: Fixed Lens: 1.8 m (5.91 ft) PT Lens: 3.6 mm: 1.7 m (5.58 ft); 8.4 mm: 6 m (19.69 ft) Iris Control Fixed Lens: Fixed Iris PT Lens: Fixed Iris DORI Distance Lens Detect Observe Recognize Identify Fixed Lens: 2.8 mm PT Lens: 3.6 mm; 8.4 mm 120 m ( 126.71 ft) 47.4 m ( 50.07 ft) 24 m ( 25.33 ft) 12 m ( 12.66 ft) DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. PTZ Pan/Tilt Range Fixed Lens: Pan: 0° to 285°; Tilt: -7° to +20° (manual) PT Lens: Pan: 0° to 350°; Tilt: 0° to +90° (Electric) Manual Control Speed Pan: 40°/s; Tilt: 40°/s Preset Speed Pan: 40°/s; Tilt: 40°/s Preset 80 Tour 8 (up to 6 presets per tour; the stay duration for each preset is 60 to 360 sec and tour interval is 900 to 3,600 sec) Power-off Memory Yes Idle Motion Preset;Tour;home position(only supports setting on DMSS) PTZ Locked YES Smart Event IVS Tripwire; Intrusion Human Detection Yes Vehicle Detection Yes Intelligence Smart Tracking Auto Tracking Lite; Linkage Tracking Lite SMD SMD 3.0 Active Deterrence Light Warning Warm light warning; Flash duration: 5 s–30 s; Flash frequency: high, medium, low Sound Warning Offers 3 sound alarm. Sound can be set from 0%–100%. Play times can be set from 1-10. Video Video Compression Smart H.265+;H.265;Smart H.264+;H.264B;H.264M;H.264H;MJPEG(Sub Stream 1) Streaming Capability 2 streams Resolution Fixed Lens: 4M (2688 × 1520); 4M (2560× 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M(1280 ×960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) PT Lens: 1080p (1920 × 1080); 1.3M (1280 ×960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) Video Frame Rate Fixed Lens: Main stream: 4M/3M/1080p/1.3M/720p@(1–25/30 fps) Sub stream: D1/VGA/CIF@(1–25/30 fps) PT Lens: Main stream: 1080p/1.3M/720p@(1–25/30 fps) Sub stream: D1/VGA/CIF@(1–25/30 fps) Bit Rate Control CBR/VBR Video Bit Rate Fixed Lens: H264: 96 kbps–8192 kbps H265: 38 kbps–8192 kbps PT Lens: H264: 64 kbps–8192 kbps H265: 25 kbps–7424 kbps Day/Night Fixed Lens: Color PT Lens: Color BLC YES WDR Fixed Lens: 120dB PT Lens: DWDR HLC YES White Balance Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp Gain Control Auto; Manual; Gain Priority Noise Reduction 2D NR; 3D NR Motion Detection Yes Region of Interest (RoI) Yes Defog Fixed Lens: Electronic PT Lens: Electronic Image Rotation 180° S/N Ratio ≥55 dB Audio Audio Compression PCM; G711A; G711Mu Built-in MIC Yes Built-in Speaker Yes Network Network Port RJ-45 (10/100 Base-T) Network Protocol HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;NTP;DHCP;DNS;DDNS;IPv6;SSL;QoS;FTP;ICMP;IGMP;ARP;RTCP;RTP;RTMP Interoperability ONVIF (Profile S & Profile G & Profile T);CGI;SDK Streaming Method Unicast/Multicast User/Host 20 (total bandwidth: 64 M) Storage Micro SD card (Up to 512 GB); FTP Browser IE 9 and later versions Chrome 41 and later versions Firefox 50 and later versions Safari 10 and later versions Management Software DMSS Mobile Client iOS;Android Function Abnormal Sound Alarm Yes Certification Certifications CE Port Audio Input 1 channel (built-in mic) Audio Output 1 channel (built-in speaker) Alarm Linkage Capture; recording; audio; light Alarm Event Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection Power Power Supply 12 VDC, 1.5A ± 25% PoE（802.3af） Power Consumption Basic: 3.9 W Max. (Basic power consumption + WDR + intelligence on + Warm light on + PTZ operation + Speaker): 12W Power Adapter Optional Environment Operating Temperature –30 °C to +55 °C (–22 °F to +131 °F) Operating Humidity ≤95% Protection IP66;TVS 2000 V lightning proof; surge protection; voltage transient protection Structure Product Dimensions 191 mm × 130 mm × 216.6 mm (7.52" × 5.12" × 8.53") (L × W × H) Net Weight 1.1 kg (2.43 lb) Gross Weight 1.7 kg (3.75 lb) Filter Remarks The precision of the presets for PTZ cameras might vary depending on different series. For scenes with high requirements on the precision, contact your local sales representative for assistance with selecting the model.
