DAHUA IVS-TB8000-2ZE-RM1 Event Detection Intelligent Server

In stock
SKU: IVS-TB8000-2ZE-RM1
Regular price $100,000.00

Estimated delivery date: 2024-06-17

无标题文档 Get More Information
Do you have any question about the Products?Contact us now via sales@cctv-mall.com.
Ask Our Experts
Text Chat | Email |04407548784511

    Order and Pricing Information for Surveillance Products
    Please note the following important details when ordering surveillance products from CCTV-MALL:
  • Minimum order amount: Orders must exceed $1000 or equivalent.
  • The prices listed, such as $1000000 or $1,534,590.00, are placeholders and do not reflect the actual prices. These products on this page are typically specialized for project-specific requirements, and pricing depends on various factors such as the required quantity and any other project-specific requirements.
  • Final pricing: Prices mentioned are subject to the final Proforma Invoice (PI) prices provided after order confirmation.
  • Shipping costs: Shipping costs will be calculated separately and added to the total order value.
  • Genuine products: We guarantee official original DAHUA products with the latest firmware versions.
  • Technical support: As authorized distributors, we provide official technical support.
  • Warranty coverage: For project-based orders, the manufacturer provides local warranty, while we offer warranty support for dealer orders.
  • If you have any questions or need further assistance, please feel free to contact us. We are committed to providing you with the best price and service for your DAHUA surveillance product needs.
Quality Certifications:



IVS-TB8000-2ZE-RM1 new-products

> Separation of rules and algorithms, based on metadata of traditional and deep learning algorithms, for the high performance of various upper-level applications.

> Adopts Dahua video cloud architecture and supports dynamic adjustment of computing resources for greater precision and control.

> Automatic detection of lane lines and key points of vehicles.

> Supports the global detection application of PTZ Camera scenes.

> Supports one-click deployment of all-in-one machines for smallscale scenarios and simple demonstrations, and supports distributed cluster deployment for large-scale scenarios.

**********

System

Main Processor



1 Intel Xeon E3-1275 V5, 3.6 GHz, 4C/8T

Chip



CentOS Linux release 7.4.1708 (Core)

Intelligence Analysis Card



2 intelligent analysis cards

Memory



4 × 8 GB DDR4 memory, maximum 4 slots

Disk



1 × 128 GB 2.5-inch SSD and 2 × 4 TB 3.5-inch HDDs

Traffic Event Detection

Multi-rules Application



Multiple rules can take effect simultaneously

Setting of Detection Area and Exclusion Area



Supports detection zone and exclusion zone for the server. The server only triggers alarms for events that occur in the detection zone or outside the exclusion zone. Supports up to 1 detection zone and 10 exclusion zones

Real-time Display



Displays detection zone rules and the target tracking box in live view. The rule and target tracking boxes flash on screen when an alarm is triggered

Parking Detection



Detects when a vehicle moves and then stops for longer than the defined threshold.

1. Intelligent Configuration

• Parking duration. Range: 1 s–600 s, 10 s by default.

• Parking threshold. 3 by default.

• Repeated alarm suppression. Supports: on and off, off by default.

• Detected priority. Supports: on and off, off by default.

• Only takes snapshots of moving vehicles. Supports: on and off, off by default.

• Takes multiple snapshots. Supports: on and off, off by default.

2. Alarm Details

1) Includes: Alarm video, alarm pictures, devices, channels, alarm start time, alarm end time, event name, event type, and plate number.

2) Alarm pictures: 2 pictures, including 1 × parking picture and 1 × picture taken 1 s after the alarm.

3) Picture overlay: Target box, target ID, detection region and target points.

Pedestrian Detection



Detects when a pedestrian walks onto the vehicle lane or into an area where pedestrians are prohibited from entering for longer than the defined threshold.

1. Intelligent Configuration

• Shortest duration. Range: 1 s–300 s, 2 s by default.

2. Alarm Details

1) Includes: Alarm video, alarm pictures, devices, channels, alarm start time, event name and event type.

2) Alarm picture: 1 picture of the pedestrian.

3) Picture overlay: Target box, target ID, detection region and target points.

Non-motor Vehicle Detection



Detects when non-motor vehicles (such as two-wheel vehicles and tricycles) drive into a restricted area, and remain there for longer than the defined threshold.

1. Intelligent Configuration

• Shortest duration. Range: 1 s–300 s, 1 s by default.

2. Alarm Details

1) Includes: Alarm pictures, alarm videos, devices, channels, alarm start time, event name and event type.

2) Alarm picture: 1 picture of non-motor vehicles.

3) Picture overlay: Target box, target ID, detection region and target points.

Traffic Jam Detection



Detects events that there is traffic jam in the lanes in the region of concern and the duration exceeds the set value. Supports reporting congestion based on lanes or areas.

1) Traffic jam on lane settings:

• Lane number

• Line occupancy ratio. Range: 1–100, 50 by default.

• Alarms in intervals. Range: 1–3,600 s, 600 s by default.

• Delay time. Range: 1–300 s, 10 s by default.

• Sensitivity. Range: 1–10, 2 by default.

• Discontinuation time threshold. Range: 1–255 s, 1 s by default.

2) Traffic jam in region settings:

• Region

• Number of vehicles in traffic jam.

• Alarms in intervals. Range: 1–3,600 s, default: 600 s.

• Delay time. Range: 1–300 s, default: 10 s.

• Sensitivity. Range: 1–10, 2 by default.

2. Alarm Details

1) Includes: Alarm pictures with the target box, alarm video, devices, channel, alarm start time, alarm end time, event name, event type, and plate number.

2) Alarm pictures: 3 types of pictures, including 1 × traffic jam picture, alarm pictures taken in intervals and 1 × picture of the end of the traffic jam.

3) Picture overlay:

Traffic jam in lane: Lane; the start and end point of the traffic jam on the lane

Region jam: Detection box

Traffic Flow Statistics



Generates statistics on the number of vehicles passing through a road section within a specified time.

1. Counts vehicles that cross the detection line on the lane. Supports counting traffic that is approaching and departing, and not specifying a direction.

2. Statistics Page

1) Displays statistics on: Lanes, traffic flow, small-sized vehicles, passenger vehicles, trucks, average speed, time occupancy ratio, space occupancy ratio, queue length, the distance between 2 vehicles, and the time between 2 vehicles passing the detection line.

2) Displays traffic flow statistics by parameters.

• Flow of approaching traffic, including information on small-sized vehicles, passenger vehicles and trucks.

• Average speed, time occupancy ratio, space occupancy ratio, queue length, the distance between 2 vehicles and the time between 2 vehicles passing the detection line.

• Shows the total traffic flow when there are more than 2 lanes.

3. The traffic flow continues to be accumulated from the last value when an operator is abnormal or the device is restarted.

4. Supports searching for traffic flow by vehicle type, including small-sized vehicle, passenger vehicle and truck.

5. Flow data can be manually cleared, and requires second confirmation.

Visibility Detection



Detects when radiation fog appears in the area for longer than the defined threshold.

1. Intelligent Configuration:

1) Shortest duration. Range: 1 s–300 s, 5 s by default.

• Alarms in intervals. Range: 1 s–65,535 s, 300 s by default.

• Alarm threshold. Range: 1–100.

2) Reports on events when the alarm starts, ends, and for the period it exists.

2. Alarm Details

1) Includes: Alarm pictures with the target box, devices, channels, start time, event name, event type, the thickness of the fog, and the time the fog dissipates.

2) Alarm pictures: 3 types of pictures, including 1 × fog picture, alarm pictures taken in intervals and 1 × picture of the dissipation of the fog.

3) Picture overlay: Target box and detection region.

Littering Detection



Detects when an object is littered by a pedestrian or a person from a vehicle and the litter disturbs traffic for longer than the defined threshold.

1. Intelligent Configuration

• Duration. Range: 1 s–300 s, 6 s by default.

• Alarms in intervals. Range: 0 s–300 s, 0 s by default.

2. Alarm Details

1) Includes: Alarm pictures with the target box, alarm video, devices, channels, alarm time, event name and event type.

2) Alarm picture: 1 picture of the littered object.

3) Picture overlay: Target box, target ID and detection region.

Intrusion Detection



Detects when vehicles enter and remain in an area for longer than the defined threshold.

1. Intelligent Configuration

1) Parameters

• Object: Pedestrian, motor vehicle, non-motor vehicle; motor vehicle by default

• Action list: Appear and cross, cross by default.

2) Sensitivity: Range: 1–10, 3 by default.

2. Alarm Details

1) Includes: Alarm pictures with the target box, devices, channels, event time, event name, event type, and plate number.

2) Alarm picture: 1 picture of the vehicle intrusion.

3) Picture overlay: Target box, target ID, detection region and lane line

Illegal Lane Change Detection



Detects when a vehicle crosses the solid yellow or white lane line for longer than the defined threshold.

1. Intelligent Configuration:

• Lane Number

• Sensitivity. Range: 1–10, 10 by default.

2. Alarm Details:

1) Includes: Devices, channels, event time, event name, event type, lane number and plate number.

2) Alarm pictures: 2 pictures, including 1 × picture of the vehicle changing lanes and 1 × picture of the vehicle after it changed the lane.

3) Picture overlay: Target box, target ID, lane line and target point.

Wrong-way Driving Detection



Detects when a vehicle is driving in the wrong direction for longer than the defined threshold. Supports reporting on the event based on the lane and region they occur in.

1. Intelligent Configuration:

• Lane number of detection region

• Duration. Range 1 s–300 s, 2s by default.

• Driving distance. Range: 0–1,023,200 by default.

2. Alarm Details

1) Includes: Alarm picture with the target box, devices, channels, event time, event name, event type, lane number and plate number.

2) Alarm pictures: 2 pictures, includiH228:H230ng 1 × picture of the vehicle driving in the wrong direction and 1 × picture taken 1 s after the alarm.

3) Picture overlay: Target box, target ID, detection region and lane line.

Illegal Backing Detection



Detects when a vehicle is illegally reversing for longer than the defined threshold. For example, when a vehicle illegally reverses on an expressway intersection.

1. Intelligent Configuration

• Detection region

• Duration. Range 1 s–300 s, 3 s by default.

• Driving distance. Range: 0–1,023. It is 200 by default.

2. Alarm Details

1) Includes: Alarm pictures with the target box, devices, channels, event time, event name, event types and plate number.

2) Alarm pictures: 2 pictures, including 1 × picture of the vehicle illegally reversing and 1 × picture taken 1 s after the alarm.

3) Picture overlay: target box, target ID and detection region

Construction Detection



Detects when construction signs are in the area for longer than the defined threshold.

1. Intelligent Configuration

1) Parameters

• Shortest duration. Range: 1 s–300 s, 5 s by default.

• Alarms in intervals. Range: 1 s–65,535 s, 300 s by default.

• Sensitivity. Range: 1–10. It is 5 by default.

• Repeated alarm suppression. Supports on and off, off by default.

2) Reports on events when the alarm starts, ends, and for the period it exists.

2. Alarm Details

1) Includes: Alarm pictures with the target box, devices, channels, start time, end time, event name and event type.

2) Alarm pictures: 3 types of pictures, including 1 × picture of the construction sign, alarm pictures taken in intervals and 1 × picture after the sign has been removed.

3) Picture overlay: Target box, target ID and detection region

Obstacle Detection



Detects objects that act as obstacles, such as boxes, in the area for longer than the defined threshold.

1. Intelligent Configuration:

1) Parameters

• Shortest duration. Range: 1 s–300 s, 5 s by default.

• Alarms in intervals. Range: 1 s–65,535 s, 300 s by default.

• Sensitivity. Range: 1–10, 1 by default.

• Repeated alarm suppression. Supports on and off, off by default.

2) Reports on events when the alarm starts, ends, and for the period it exists.

2. Alarm Details

1) Includes: Alarm pictures with the target box, devices, channels, start time, time object was removed, event name and event type.

2) Alarm pictures: 3 types of pictures, including 1 × picture of the object acting as an obstacle, alarm pictures taken in intervals and 1 × picture after the object has been removed.

3) Picture overlay: Target box, target ID and detection region

Accident Detection



Detects when vehicles collide, and the collision lasts longer than the defined threshold.

1. Intelligent Configuration:

• Alarms in intervals. Range: 1–600 s, 600 s by default.

• Parking duration. Range: 1 s–300 s, 50 s by default.

• Duration of pedestrian in area. Range: 1 s–300 s, 3 s by default.

• Vehicle in traffic congestion. Range: 1-300, 14 by default.

2. Alarm Details:

1) Includes: Alarm pictures with the target box, devices, channels, start time, event name and event type.

2) Alarm pictures: 2 pictures, including 1 × picture of the vehicle collision and 1 × picture taken 1 s after the alarm.

3) Picture overlay: Target box and detection region

Fire Detection



Detects when a fire breaks out in the area, and lasts longer than the defined threshold.

1. Intelligent Configuration

• Shortest duration. Range: 1 s–300 s, 5 s by default.

• Sensitivity. Range: 1–10, 5 by default.

• Alarms in intervals. Range: 1 s–300 s, 10 s by default.

• Overlap threshold. Range: 0–100, 90 by default.

2. Alarm Details: 1 × alarm picture with the target box, devices, channels, event time, event name and event types.

Smoke Detection



Detects when smog appears and remains in the area for longer than the defined threshold.

1. Intelligent Configuration:

• Shortest duration. Range: 1 s–300 s, 5 s by default.

• Sensitivity. Range: 1–10, 5 by default.

• Alarms in intervals. Range: 1 s–300 s, 10 s by default.

• Overlap threshold. Range: 0–100, 90 by default.

2. Alarm Details: 1 × Alarm picture with the target box, devices, channels, event time, event name and event type.

Crossing Line Detection



Detects when a vehicle crosses the solid yellow or white line for longer than the defined threshold.

1. Intelligent Configuration:

• Lane lines

• Duration. Range: 1 s–300 s, 5 s by default.

• Takes snapshots when a vehicle crosses the solid white line. It is off by default.

• Sensitivity. Range: 1–10, 5 by default.

2. Alarm Details:

1) Includes: Alarm pictures with the target box, devices, channels, event time, event name, event type, lane number and plate number.

2) Alarm pictures: 2 pictures, including 1 × picture of the vehicle crossing the solid line and 1 × picture taken 1 s after the alarm.

3) Picture overlay: Target box, Target ID, Lane line and Target point.

Speeding Detection



Detects when the speed of a vehicle exceeds the defined threshold, and remains above the threshold for longer than the defined time.

1. Intelligent Configuration:

• Lane number

• Maximum speed. Range: 60 km/h–180 km/h. It is 120 km/h by default.

• Shortest duration. Range: 1 s–300 s, 5 s by default.

2. Alarm Details:

1) Includes: Alarm pictures with the target box, devices, channels, event time, event name, event types, lane number, plate number, maximum speed and driving speed.

2) Alarm pictures: 2 pictures, including 1 × vehicle speeding picture and 1 × picture taken 1 s after the alarm.

3) Picture overlay: target box, target ID, and lane line.

Driving Too Slow Detection



Detects when the speed of a vehicle falls below the defined threshold, and remains below the threshold for longer than the defined time.

1. Intelligent Configuration:

• Lane number

• Minimum speed. Range: 30 km/h–120 km/h. It is 60 km/h by default.

• Shortest duration. Range: 1 s–10 s, 1 s by default.

2. Alarm Details:

1) Includes: Alarm pictures with the target box, devices, channels, event time, event name, event types, lane number, plate number, maximum speed and driving speed.

2) Alarm pictures: 2 pictures, including 1 × picture of the vehicle driving too slow and 1 × picture taken 1 s after the alarm.

3) Picture overlay: Target box, target ID, and lane line.

Detection of Trucks Entering Prohibited Area



Detects when a truck enters the detection zone.

1. Intelligent Configuration:

• Sensitivity. Range: 1–10, 3 by default.

2. Alarm Details:

1) Includes: Alarm pictures with the target box, devices, channels, event time, event name, event type and plate number.

2) Picture overlay: Target box, target ID, lane line and target point.

Detection of Hazardous Material Transport Vehicle



Detects when a hazardous material transport vehicle crosses the detection line.

1. Intelligent Configuration:

• Sensitivity. Range: 1–10, 3 by default.

• Hazardous material transport vehicle. It is tank car by default.

2. Alarm Details:

1) Includes: Alarm pictures with the target box, devices, channels, event time, event name, event type and plate number.

2) Picture overlay: Target box, target ID, lane line and target point.

Detection of Driving in Emergency Lane



Detects when a vehicle enters the emergency lane.

1. Intelligent Configuration:

• Sensitivity. Range: 1–10, 3 by default.

2. Alarm Details:

1) Includes: Alarm pictures with the target box, devices, channels, event time, event name, event type and plate number.

2) Picture overlay: Target box, target ID, lane line and target point.

License Plate Recognition



Support ANPR for parking, illegal lane change, crossing solid yellow line, wrong-way driving, and intrusion. It is recommended that the license plate width is more than 80 pixels.

Report Generation and Export



Exports alarm information in Excel form, including device, device IP, channel name, event time, event name, event type, lane, license plate number, speed and more

Alarm Search



Supports searching for alarm information according to multiple options, such as device, channel, event type, capture time and more

Global Detection



Supports global detection mode for one channel. After global detection mode is enabled, one channel can enable global detection.

1. Lane lines and detection regions are automatically detected.

2. Rule parameters can be configured

3. The lane lines and detection zones can be updated in real time.

4. Available options through the algorithm: Parking, pedestrian on vehicle lane, non-motor vehicle, traffic jam, littering, wrong-way driving, reversing, construction, obstacle, traffic accident, radiation fog, smoke and fire detection.

Alarm Video



1. Alarm videos can be enabled by event.

2. The duration can be configured by event. Range: ±5 s–180 s, ±15 s by default.

3. Supports configuring the video storage disk through the client. It also notifies of full cycle coverage and storage space overflow.

4. The alarm video contains smart frames, and the client performs filtering during playback and decoding. Only the smart frames and target IDs related to the alarm rules cannot be filtered out.

5. Displays the video on the alarm details page. Video recordings can also be played. Supports adjusting the control bar of the video, and notifying when the video corresponding to the event is still being generated while it is being played.

6. Supports downloading alarm videos in .mp4 format (without smart frame) and .dav format (with smart frame). The default format is .mp4.

7. Hard disks can be mounted and unloaded.

Application of Traffic Event Detection

Scenario Type



Widely used in traffic management, road operations and maintenance scenarios such as expressways, urban expressways, viaducts, tunnels, and cross-sea bridges

Camera Installation Method



Front installation (recommended) and side installation

Camera Installation Height



6–12 meters recommended, two or three lanes can be captured

Camera Installation Angle



Recommended pitch angle is between 10°–15°, covering about 50 m–100 m (164.04 ft–328.08 ft) and lane inclination angle < 30° when side-mounted

Traffic Event Detection Performance

Video Resolution



1080p and above

Camera Access



In xZE, ZE means intelligent analysis cards and x means a set number. (xZE = the number of channels that can be analyzed, for example 2 cards can be used to analyze 32 channels.) A single card can be connected to multiple 16-ch 1080p cameras at the same time. For more information, please check the product overview.

Traffic Event Detection Type



Parking detection, pedestrian detection, non-motor vehicle detection, congestion detection, traffic flow statistics, littering detection, intrusion, illegal lane change, wrong-way driving detection, vehicle backing detection, construction detection, obstacle detection, accident detection, fog detection, smoke detection, fire detection, line crossing detection, overspeed detection, low speed detection, prohibited entry of trucks, dangerous goods vehicles, driving in emergency lane

Traffic Parameters Collection



Traffic flow, average speed, time occupancy rate, space occupation rate, space headway, time headway and queue length

Parking Detection



According to test data (1080p access), the detection rate is 90%, and the effective rate is 90%.

Pedestrian Detection



According to test data (1080p access), the detection rate is 90%, and the effective rate is 90%.

Non-motor Vehicle Detection



According to test data (1080p access), the detection rate is 90%, and the effective rate is 90%.

Traffic Jam Detection



According to test data (1080p access), the detection rate is 90%, and the effective rate is 90%.

Traffic Flow Statistics



According to test data (1080p access), the traffic accuracy rate is over 90%.

Visibility Detection



Subject to actual test

Littering Detection



According to test data (1080p access), the detection rate is 80%, and the effective rate is 80%.

Intrusion Detection



According to test data (1080p access), the detection rate is 90%, and the effective rate is 90%.

Illegal Lane Change Detection



According to test data (1080p access), the detection rate is 90%, and the effective rate is 90%.

Wrong-way Driving Detection



According to test data (1080p access), the detection rate is 90%, and the effective rate is 90%.

Illegal Backing Detection



According to test data (1080p access), the detection rate is 90%, and the effective rate is 90%.

Construction Detection



According to test data (1080p access), the detection rate is 90%, and the effective rate is 80%.

Obstacle Detection



According to test data (1080p access), the detection rate is 90%, and the effective rate is 90%.

Accident Detection



Subject to actual test

Fire Detection



Subject to actual test

Smoke Detection



Subject to actual test

Crossing Line Detection



According to test data (1080p access), the detection rate is 90%, and the effective rate is 90%.

Speeding Detection



Subject to actual test

Driving Too Slow Detection



Subject to actual test

Detection of Trucks Entering Prohibited Area



Subject to actual test

Detection of Hazardous Material Transport Vehicle



Subject to actual test

Detection of Driving in Emergency Lane



Subject to actual test

Global Detection



The card supports 16-ch video stream. One card can have up to 16 channels, and 20 rules can be configured for each channel.

Alarm Video



1. Supports caching up to 32 channels (within 4 MP). Each card can have 32 channels.

2. Up to 32 task video (within 4 MP) can be written to HDDs at the same time.

3. Supports playing videos on up to 4 channels at the same time.

Port

Network Port



4 × 10,000/1,000 Mbps gigabit Ethernet ports

RS-232



1 RS-232 debugging serial port

USB



2 front USB 3.0 ports and 2 rear USB3.0 ports

VGA



1 VGA ports

Others



1 BMC management network port

General

Power Supply



100–127/200–240 VAC, 50/60 Hz, 7/3.5 A

Power Redundancy



Dual

Power Consumption



100 W (without HDD, idling)

200 W (all HDDs connected, with 2 intelligent analysis cards)

Operating Temperature



+10 °C to +35 °C (+50 °F to +95 °F)

Operating Humidity



8%–90% (RH), non-condensing

Storage Temperature



–40 °C to +65 °C (–40 °F to + 149 °F)

Storage Humidity



5%–95% (RH), non-condensing

Gross Weight



20.3 kg (44.75 lb)

Net Weight



15.6 kg (34.39 lb)

Product Dimensions



661.3 mm × 438.5 mm × 43.5 mm (26.04" × 17.26" × 1.71") (D × W × H)

Packaging Dimensions



895 mm × 625 mm × 271 mm (35.24" × 24.61" × 10.67") (D × W × H)

Installation



Standard 19" rack installation with guide rail

Optional

Product Type



All-in-one server integrated software and hardware

********

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
