Performance

Image Sensor Size

1.1"

Focal Length

50 mm

Lens Pixel

12 MP

Aperture

F1.4 ± 10%

IR Light

Yes

CRA

10.3°

Total Optical Length

84 mm ± 0.5 mm (3.31" ± 0.02") (in air)

Flange Back Focal Length

17.53 mm ± 0.2 mm (0.69" ± 0.01") (in air)

Mechanical Back Focal Length

9.87 mm ± 0.2 mm (0.39" ± 0.01") (in air)

Field of View

1.1":
20.9° × 17.2° × 11.6° (@17.56 × 14.47 × 9.94 mm)
1":
18.7° × 16.5° × 8.7° (@16.1 × 14.13 × 7.45 mm)

Distortion

–1.3%

Minimum Object Distance (MOD)

1 m (3.28 ft)

Control Mode

Zoom

Fixed

Focus Control

Manual

Iris Control

Manual

Port

Port Type

Structure

Product Dimensions

Ф56 mm × 80.2 mm (Ф2.2" × 3.16")

Appearance Color

Black

Casing

Metal

Net Weight

0.335 kg ± 0.005 kg (0.74 lb ± 0.01 lb)

Gross Weight

0.4 kg ± 0.010 kg (0.88 lb ± 0.02 lb)

Packaging Method

30 pieces in one carton

Packaging Dimensions

Package: 124 mm × 82 mm × 89 mm

(4.88" × 3.23" × 3.5") (L × W × H)
Protection box: 265 mm × 265 mm × 470 mm (10.43" × 10.43" × 18.50") (L × W × H)

Environment

Operating Temperature

–30 °C to +70 °C (–22 °F to +158 °F)

Operating Humidity

≤ 95% (RH)

Storage Temperature

–30 °C to +70 °C (–22 °F to +158 °F)

Storage Humidity

≤ 95% (RH)
