Hardware

Included Power Adapter

No

PoE

Yes

Ethernet Port

16

Optical Port

4

Ethernet Port Speed

10 Mbps/100 Mbps/1000 Mbps

Optical Port Speed

1000 Mbps

Console Port

1

Power Supply Mode

48 V–57 V DC

Operating Temperature

–40 °C to +75 °C (–40 °F to +167 °F)

Operating Humidity

5%–95% (non-condensing)

Power Consumption

Idling: ≤ 15 W
Full load: 240 W

Performance

Layer

L2

Managed

Yes

Switching Capacity

54 Gbps

Packet Forwarding Rate

28.28 Mpps

Packet Buffer Size

4 Mbits

Communication Standard

IEEE 802.3; IEEE 802.3u; IEEE 802.3x; IEEE 802.3ab; IEEE 802.3z; IEEE 802.3ad

MAC Table Size

8K

Function

PoE Protocol

IEEE 802.3af (PoE); IEEE 802.3at (PoE+); Hi-PoE; IEEE 802.3bt

PoE Power

Port 1-2: ≤ 90 W
Port 3-16: ≤ 30 W
Total: ≤ 240 W

PoE Power Consumption Management

Power consumption management
PoE power on and off
Power off when PoE power is overloaded
Green PoE

PoE Pin Assignment

1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)

Long Distance PoE Transmission

Yes

Jumbo Frame

9,000 bytes

Spanning Tree Protocol

ERPS

VLAN Function

802.1Q

Flow Control

IEEE 802.3X-based flow control

Link Aggregation

Static link aggregation; LACP

Port Mirroring

Multiple-to-one port mirroring

Multicast

Yes

DHCP Function

DHCP client

Security

IEEE 802.1x-based port authentication
Port-based MAC address binding

QoS

Priority, WRR
802.1P, DSCP

Maintenance

One-click restore to default settings
Uploading/downloading configuration files
Software upgrade
System logs

Device Management

Web; SSH; SNMP

General

Statics Protection

Air discharge: 15 kV
Contact discharge: 8 kV

Lighting Protection

Common mode: 6 kV
Differential mode: 4 kV

Net Weight

1.35 kg (2.98 lb)

Gross Weight

1.75 kg (3.9 lb)

Product Dimensions

125.4 mm × 75.0 mm × 175.0 mm (4.9" × 3.0" × 6.9 ") (L × W × H)

Packing Dimensions

325 mm × 190 mm × 125 mm (12.8" × 7.5" × 4.9") (L × W × H)

Transmission Performance:

Switch power supply voltage 53V.

CAT5E/CAT6. Max. DC resistance < 10 Ω/100 m

Cable(m)

Load Capacity(W)

Bandwidth(Mbps)

IEEE802.3bt 90 W

100

71.3

100

150

62

10

200

51

10

250

40

10

Hi-PoE 60 W

100

53

100

150

50

10

200

47

10

250

37

10

IEEE802.3at 30 W

100

25.5

100

150

25.5

10

200

25.5

10

250

25.5

10

Note: Data from this table was collected by Dahua test lab and is for reference only . The actual transmission distance may vary due to power consumption of connected devices or the cable type and status.
