DAHUA IVSS7012-4M 2U 12HDDs WizMind Intelligent Video Surveillance Server

In stock
SKU: IVSS7012-4M
Regular price $10,692.00
Our standard leading time is estimated to be 30 working days, even if it is shown as in stock, please confirm this lead time before purchasing.
无标题文档 Get More Information
Do you have any question about the Products?Contact us now via sales@cctv-mall.com.
Ask Our Experts
Text Chat | Email |04407548784511

    Order and Pricing Information for Surveillance Products
    Please note the following important details when ordering surveillance products from CCTV-MALL:
  • Minimum order amount: Orders must exceed $1000 or equivalent.
  • The prices listed, such as $1000000 or $1,534,590.00, are placeholders and do not reflect the actual prices. These products on this page are typically specialized for project-specific requirements, and pricing depends on various factors such as the required quantity and any other project-specific requirements.
  • Final pricing: Prices mentioned are subject to the final Proforma Invoice (PI) prices provided after order confirmation.
  • Shipping costs: Shipping costs will be calculated separately and added to the total order value.
  • Genuine products: We guarantee official original DAHUA products with the latest firmware versions.
  • Technical support: As authorized distributors, we provide official technical support.
  • Warranty coverage: For project-based orders, the manufacturer provides local warranty, while we offer warranty support for dealer orders.
  • If you have any questions or need further assistance, please feel free to contact us. We are committed to providing you with the best price and service for your DAHUA surveillance product needs.
Quality Certifications:



2U 12HDDs WizMind Intelligent Video Surveillance Server

> Industry embedded micro-controller

> Max 400 Mbps incoming bandwidth

> 128-channel IP video access

> Up to 48-channel AI IVS

> Up to 48-channel face recognition with normal IPC

> Up to 128-channel face recognition with face detection IPC

> Up to 48-channel video metadata

> Up to 50 face databases with 500,000 face pictures in total

> Supports RAID 0/1/5/6/10/50/60

> 3 HDMI/2 VGA video output

Products Specifications



Main Processor

Industry embedded micro-controller

Operating System

Embedded Linux OS

Operation Interface

WEB (PCAPP), local GUI

AI Applications

AI by Camera

Face detection, face recognition, video metadata,

IVS (tripwire, intrusion, abandoned object, missing object, fast moving, parking detection, crowd gathering, loitering, parking, and fence-crossing),

people counting, smoking detection, call detection

AI by Device

Face detection, face recognition, video metadata,

IVS (tripwire, intrusion, crowd gathering, loitering detection, parking detection), plate comparison


IVS Performance (AI by Device) (Channel Number)

48-channel 2 MP or 32-channel 4 MP with normal IP camera

IVS Performance (AI by Camera) (Channel Number)


Human Face Detection

Human Face Properties

Supports 6 properties: Gender, age range (6 levels), glasses, expression (8 types), mouth mask, and beard

Face Detection Performance (AI by Device) (Channel Number)

48-channel 2 MP or 32-channel 4 MP with normal IP camera

Face Detection Performance (AI by camera) (Channel Number)


Human Face Recognition

Face Database Capacity

50 face databases with 500,000 face pictures in total

Human Face Recognition Performance (AI by Device) (Channel Number)

48-channel 2 MP or 32-channel 4 MP with normal IP camera

128-channel with face detection IP camera (Totally 160 face pictures analyzed per second)

Human Face Recognition Performance (AI by camera) (Channel Number)



Plate Database Capacity

50 plate databases with 500,000 plate numbers in total

Supports allowlist and blocklist

Plate Detection Performance by ITC Camera (Channel Number)


Video Metadata

Human Body Properties

Gender, age, sleeves length, top color, bottom type, bottom color, bag, rain coat, umbrella, hat, hairstyle, direction, hold a baby, mouth mask

Vehicle Properties

Vehicle type, vehicle color, plate color, logo, calling, seatbelt, ornament, region

Non-motorized Vehicle Properties

Non-motor Vehicle type, non-motor vehicle color, number of passengers, umbrella, rain coat,bag , sleeve length, top color, hat, hair style, mouth mask

Metadata Performance (AI by Device) (Channel Number)

48-channel 2 MP or 32-channel 4 MP with normal IP camera

Metadata Performance (AI by camera) (Channel Number)


Video Parameters

Remote Connection


Network Bandwidth

Incoming bandwidth: 400 Mbps
recording bandwidth: 320 Mbps
outgoing bandwidth: 96 Mbps



Decoding Capability

1-channel 24MP/2-channel 16MP/5-channel 12MP (20 fps)/6-channel 12MP (15 fps)/5-channel 8MP (30 fps)/10-channel 8MP (15 fps)/6-channel 6MP (30 fps)/8-channel 5MP(30 fps)/9-channel 5MP (25 fps)/10-channel 4MP (30 fps)/15-channel 4MP (20 fps)/16-channel 3MP (25 fps)/10-channel 1080p (60 fps)/20-channel 1080p (30 fps)/30-channel 720p (30 fps)

Video Output

2-channel VGA output, 3-channel HDMI output, VGA 1/HDMI 1 outputs the same video source. VGA2/HDMI2 outputs the same video source. Supports 4K output

Multi-screen Display

1st Screen: Max.64-channel

2nd Screen: Max.16-channel

3rd Screen: Max.1-channel

Third-party Support

Onvif; RTSP; Sony; Panasonic; Axis; Arecont; Pelco; Canon; Samsung

Operating System

Embedded Linux OS

Operation Interface

WEB (PCAPP), local GUI


Video Compression

Smart H.265+; Smart H.264+; H.265; H.264

Audio Compression

G.711a; G.711u; PCM; G.726




Mobile Phone



ONVIF (Profile S, T and G); CGI; SDK


Chrome; PCAPP; IE9 or higher; Firefox

Network Mode

NIC binding mode such as multiple-address mode, load balance, fault-tolerance, etc

Record Playback

Multiple-channel Playback

Max. 16-channel playback

Record Search

Search video detection/manual record/IO alarm/intelligent event/all record file

Storage Medium

Internal HDD, SAS disk array enclosure

Backup Method

HDD, peripheral USB storage device

Playback Function

Play, pause, stop, fast forward, fast backward, reverse play, frame by frame play

Full-screen, backup (clip/file), snapshot, digital zoom, audio on/off


HDD Group



RAID 0/1/5/6/10/50/60

Storage Pool



General Alarm

Motion detect, tampering, local alarm

Anomaly Alarm

IPC offline alarm, storage error, HDD full, IP conflict, MAC conflict, login lock, AI module temperature alarm, AI module offline, fan malfunction

Intelligent Alarm

Human face detection, human face recognition, entries frequency, video metadata (person/vehicle/non-motor vehicle), IVS, plate recognition, people counting, smoking, call

Alarm Linkage

Record, snapshot (full image), local external alarm output, IPC external alarm output, access & control, audio prompt, buzzer, log, preset, email

Peripheral Interface

Audio Input

1-channel, RCA port (reserved)

Audio Output

2-channel, RCA port, speaker output, audio linkage output

Alarm Input


Alarm Output


Internal HDD

12 slots, SATA3.0/SAS. Max. 16T/HDD


1 port


1 SAS2.0 port


1 port, for debug or transparent COM data


1 port, control peripheral PTZ and so on

Supports various protocols


4 ports

2 USB3.0 ports at the front panel and 2 USB3.0 ports at the rear panel


3 ports; support 4K output


2 ports


4 RJ-45 10/100/1000 Mbps self-adaptive Ethernet ports


1 port



General Parameters

Power Supply

100 VAC–240 VAC 50-60 Hz

Power Consumption

100 W (without HDD, idling)

244 W (all HDDs connected)

Net Weight

13.5 kg (29.76 lb)

Gross Weight

14.0 kg (30.86 lb)


(W × L × H)

Chassis: 447.6 mm × 604.3 mm × 87.0 mm

(17.62" × 23.79" × 3.43")
Max. size: 482.6 mm (with hanger) × 604.3 mm × 87.0 mm (with feet mat) (19.00" × 23.79" × 3.43")

Packaging Dimensions

(W × L × H)

With Packaging: 654 mm × 834 mm × 201 mm

(25.74" × 32.83" × 7.91 ")
Protection box: 625 mm × 895 mm × 271 mm

(24.60" × 35.24" × 10.67")

Operating Conditions

0 °C to +45 °C (+32 °F to +113 °F)/10%RH–90%RH

Strorage Conditions

-20 °C to +70 °C (-4 °F to +158 °F)

Operating Altitude

5000 m (16404.20 ft)

Installation Mode



CE: CE-LVD: EN 60950-1/IEC 60950-1

CE-EMC: EN55024,EN55035, EN50130-4,EN60950-1

FCC: Part 15 Subpart A

UL: 60950-1 and CAN/CSA C22.2 No. 60950-1-07
