Dahua IPC-HDBW3449R1-ZAS-PV-PRO 4MP TiOC PRO WizColor Dome Network Camera
Regular price
$10,000.00
Couldn't load pickup availability
Our standard leading time is estimated to be 30 working days, even if it is shown as in stock, please confirm this lead time before purchasing.
Do you have any question about the Products?Contact us now via sales@cctv-mall.com.
 |
 |
Ask Our Experts
|
Please note the following important details when ordering surveillance products from CCTV-MALL: |
Quality Certifications: |
Dahua IPC-HDBW3449R1-ZAS-PV-PRO 4MP WizColor TiOC PRO Vari‑focal Dome WizSense Network Camera – 2.7‑12mm F1.2 Zoom, Red & Blue Warning Lights
4MP WizColor TiOC PRO Dome – Active Deterrence & Exceptional Low‑Light Performance
- 4MP Ultra‑HD Imaging: 2688×1520 resolution from a large 1/1.8" CMOS sensor. Motorized 2.7‑12mm F1.2 zoom (4.4x) with ultra‑bright aperture.
- WizColor Technology: Exceptional low‑light color imaging down to 0.0003 lux – delivers vibrant, detailed images in near darkness without white light.
- TiOC PRO Active Deterrence: Red & blue warning lights, sound alarm, and warm light triggered by intrusion – instantly deters intruders.
- Built‑in Dual Mic & Speaker: Secure real‑time two‑way talk and audio alarm broadcast.
- Advanced AI & AcuPick: Xinghan Vision Models, SMD 4.0, AcuPick (fast human/vehicle search), IVS perimeter protection (intrusion/tripwire with human/vehicle classification), face detection (full image).
- 120dB True WDR & AI Coding: 120dB WDR ensures clarity in backlight; AI H.265/H.264 (Smart H.265+/H.264+) reduces bandwidth and storage.
- Rugged Vandal‑proof Dome: Metal casing, IP67 weatherproof, IK10 vandal‑resistant, 3‑axis adjustment (Pan 355°, Tilt 80°, Rotation 355°), operating temperature -30°C to +60°C.
Camera Specification
| Image Sensor | 1/1.8" CMOS |
|---|---|
| Max. Resolution | 2688 × 1520 (4MP) |
| ROM / RAM | Not specified (standard WizSense AI architecture) |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.0003 lux @ F1.2 (Color, 30 IRE); 0.0001 lux (B/W); 0 lux (illuminator on) |
| S/N Ratio | >56 dB |
| Illumination Distance / Type | IR up to 50 m, warm light up to 50 m (4 multi‑core IR+warm LEDs); Zoomprio control |
| Angle Adjustment | Pan: 0°–355°, Tilt: 0°–80°, Rotation: 0°–355° |
Lens & DORI Optics
| Lens Type / Mount | Motorized vari-focal (Φ16 mount) | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Focal Length / Aperture | 2.7 mm–12 mm (4.4x optical zoom) | F1.2 | |||||||||||||||
| Iris Control | Fixed | |||||||||||||||
| Field of View | H: 114°–48°, V: 59°–27°, D: 143°–56° | |||||||||||||||
| Close Focus Distance | 1.75 m (5.74 ft) | |||||||||||||||
| DORI Distance |
*DORI standard (EN-62676-4). For intelligent function distances, refer to project design tool.
|
| AI Functions | Perimeter protection (IVS), SMD 4.0, AcuPick, face detection (full image), AI SSA (scene self‑adaptation) |
|---|---|
| IVS Perimeter Protection | Intrusion, tripwire (human/vehicle classification), stay detection, loitering detection. Large‑scale AI models extend detection range and reduce false alarms. |
| SMD 4.0 | Smart Motion Detection – filters out false alarms caused by environmental changes. |
| AcuPick | Deep learning target matching with back‑end NVR for rapid human/vehicle search. |
| Face Detection (Full Image) | Face detection, snapshot optimization, face exposure, face angle filter, snapshot strategies (real‑time/quality/optimization). |
Video & Audio Specifications
| Video Compression / AI Coding | H.265; H.264; H.264H; H.264B; MJPEG (sub stream) | AI H.265 / AI H.264 (Smart H.265+/H.264+) |
|---|---|
| Streaming Capability | 3 streams (main, sub, third) |
| Resolution | 4M (2688×1520/2560×1440), 3M, 1080p, 720p, D1, VGA, CIF |
| Video Frame Rate | Main: 4MP @ 25/30 fps; Sub: 1080p @ 25/30 fps; Third: 1080p @ 25/30 fps |
| Bit Rate Control / Range | VBR, CBR, ABR | H.264/H.265: 3–16384 kbps |
| WDR & Image Enhancements | 120 dB WDR; SSA; BLC; HLC; 3D NR; ROI (4 areas); Defog; Mirror; Smart Illumination; EIS |
| Special Features | Image Rotation, Privacy Masking (8 areas) |
| Audio Features |
Built-in Dual Mic + Built-in Speaker (two‑way talk) Audio Compression: PCM; G.711a; G.711Mu; G.726; G.723 External: 1‑ch RCA input, 1‑ch RCA output |
| Network Port | RJ-45 (10/100/1000 Base-T) Gigabit Ethernet |
|---|---|
| Network Protocols | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Bonjour; Auto Registration |
| Interoperability / Browser | ONVIF (Profile S/G/T/M); CGI | IE, Chrome, Firefox |
| Local Storage | Micro SD card (max. 512 GB); FTP; SFTP; NAS |
| Cybersecurity | Digest; WSSE; Account lockout; Security logs; 802.1x; IP/MAC filtering; HTTPS; Syslog; Trusted boot/execution/upgrade; Session security; X.509 certification. |
| Management Software | SmartPSS Lite; DSS; DMSS; DoLynk Care | iOS & Android |
Physical I/O Interfaces
| RS-485 | Not specified |
|---|---|
| Audio I/O | 1‑ch RCA input, 1‑ch RCA output (in addition to built‑in dual mic & speaker) |
| Alarm I/O | 1 alarm input (wet/dry contact), 1 alarm output (dry contact, 1000 mA 30 VDC / 500 mA 50 VAC) |
| Analog Output | Not specified |
| Power Output | Not specified |
| Alarm Events | Extensive list including SD card errors, network issues, motion, tampering, tripwire, intrusion, loitering, stay, scene changing, audio detection, defocus, face detection, SMD, security exception, etc. |
| Power Supply | 12 VDC (±30%), PoE+ (802.3at); Dual Power Backup (hot‑swap without restart) |
|---|---|
| Power Consumption | Basic: 4.1 W (12 VDC), 5.7 W (PoE) Max (H.265 + WDR + warm light + active deterrence + AI on): 12.1 W (12 VDC), 16.1 W (PoE) |
| Operating Temperature / Humidity | –30 °C to +60 °C (–22 °F to +140 °F) | ≤95% RH (non‑condensing) |
| Storage Temperature / Humidity | –40 °C to +60 °C, ≤95% RH |
| Protection Ratings | IP67 (weatherproof), IK10 (vandal‑proof) |
| Anti‑corrosion Level | Basic Protection (designed for general use) |
| Casing Material | Metal |
|---|---|
| Product Dimensions | 105.0 mm × Φ126.0 mm (4.13" × Φ4.96") (H × D) |
| Net Weight / Gross Weight | 0.75 kg (1.65 lb) / 0.99 kg (2.18 lb) |
