Dahua IPC-HFE8841S-AS 8MP Explosion-proof IR Bullet WizMind Network Camera
Regular price
$350.00
Couldn't load pickup availability
Our standard leading time is estimated to be 30 working days, even if it is shown as in stock, please confirm this lead time before purchasing.
Do you have any question about the Products?Contact us now via sales@cctv-mall.com.
 |
 |
Ask Our Experts
|
Please note the following important details when ordering surveillance products from CCTV-MALL: |
Quality Certifications: |
Dahua IPC-HFE8841S-AS 8MP Explosion-Proof IR Bullet WizMind Network Camera – ATEX/IECEx, IP68, NEMA 4X
Key Performance Highlights – Explosion-Proof Design with Full WizMind AI Suite
- 8MP Ultra-HD Imaging: 1/2.8" CMOS delivers 3840×2160 resolution for exceptional forensic detail.
- Explosion-Proof Certified: ATEX & IECEx certified (TÜV 24 ATEX 9126 X / IECEx TUR 24.0026X) – safe for hazardous environments.
- Rugged All-Weather Protection: High-strength aluminum alloy casing, IP68 (submersible), NEMA 4X anti-corrosion (moderate protection for coastal/acid rain areas).
- WizMind Elite Intelligence: Over 6 AI functions including SMD 4.0, AcuPick, face detection (6 attributes/8 expressions), people counting (tripwire/area/queue), heat map, IVS (intrusion/tripwire/fast moving/loitering/parking/people gathering), abandoned/missing object.
- Superior Low-Light & WDR: 0.007 lux color, 0.0007 lux B/W, 120dB True WDR, AI SSA scene adaptation, 3D NR, defog – clear imaging in any condition.
- 50m IR Night Vision: Single powerful IR LED with Smart IR provides up to 164 feet of illumination.
- Flexible Lens Options: Choose 3.6 mm (84° H FOV) or 6 mm (52.8° H FOV) fixed-focal lenses to suit your coverage needs.
- Efficient AI Encoding & Storage: AI H.265/H.264, Smart H.265+/H.264+, supports Micro SD up to 512 GB, FTP, NAS, and 80 Mbps total bandwidth.
Camera Specification – 8MP Explosion-Proof
| Image Sensor | 1/2.8" CMOS | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Max. Resolution | 8MP – 3840 (H) × 2160 (V) – 4K Ultra-HD | |||||||||||||||
| ROM / RAM | 512 MB / 2 GB | |||||||||||||||
| Scanning System | Progressive | |||||||||||||||
| Electronic Shutter Speed | Auto/Manual 1/3 s – 1/100,000 s | |||||||||||||||
| Min. Illumination | Color: 0.007 lux@F1.6 (30 IRE); B/W: 0.0007 lux@F1.6 (30 IRE); 0 lux (IR on) | |||||||||||||||
| S/N Ratio | >56 dB | |||||||||||||||
| Illumination Distance & Type | IR: Up to 50 m (164.04 ft) – 1 IR LED | |||||||||||||||
| Illuminator Control | Auto; Manual |
| Lens Type / Mount | Fixed-focal / M12 | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Available Focal Lengths | 3.6 mm (F1.6) or 6 mm (F1.6) | |||||||||||||||
| Field of View | 3.6 mm: H:84°, V:47.8°, D:96.5° 6 mm: H:52.8°, V:30.3°, D:60.3° |
|||||||||||||||
| Close Focus Distance | 3.6 mm: 2.0 m (6.56 ft); 6 mm: 3.6 m (11.81 ft) | |||||||||||||||
| Iris Control | Fixed | |||||||||||||||
| DORI Distance (EN-62676-4) |
|
WizMind Elite Intelligence – Full AI Suite
| SMD 4.0 | Smart Motion Detection with human/vehicle classification. |
|---|---|
| IVS (Perimeter Protection) | Intrusion, tripwire, fast moving (with human/vehicle classification); loitering detection, people gathering, parking detection. |
| Smart Event | Abandoned object; missing object. |
| Face Detection | Track, snapshot, optimization, face enhancement, attribute extraction (6 attributes, 8 expressions), face cutout (face/one-inch photo), snapshot strategies (real-time, quality priority, optimization), face angle filter. |
| People Counting | Tripwire people counting (day/week/month/year report), area counting, queue management (queue number/time alarm). Supports up to 4 rules. |
| Heat Map | Yes – visualize frequently visited areas. |
| AcuPick | Deep learning with backend devices for accurate human/vehicle target matching and fast search across live/recorded video. |
| AI SSA (Scene Self-Adaptation) | Deep learning adjusts image parameters to suit environmental conditions. |
| AI Coding | AI H.265; AI H.264 – intelligent encoding for bandwidth/storage efficiency. |
| Smart Search | Works with Smart NVR for refined event extraction and merging. |
Video & Audio Specifications – 3 Streams, 120dB WDR
| Compression / Smart Codec | Smart H.265+; H.265; Smart H.264+; H.264; H.264H; H.264B; MJPEG (sub stream only) AI Coding: AI H.265; AI H.264 |
|---|---|
| Streaming Capability | 3 streams |
| Resolution Options | 8M (3840×2160), 6M (3200×1800), 5M (3072×1728), 4M (2688×1520/2560×1440), 3M (2304×1296), 1080p, 720p, D1, VGA, CIF |
| Video Frame Rate | Main: 3840×2160 @ 1–25/30 fps; Sub: D1 @ 1–25/30 fps; Third: 1920×1080 @ 1–25/30 fps |
| Bit Rate Control / Bit Rate | VBR; CBR; ABR. H.264/H.265: 3 kbps – 16384 kbps |
| WDR / Image Enhancements | 120 dB True WDR, BLC, HLC, 3D NR, SSA, Defog, ROI (4 areas), Mirror, Image Rotation (0/90/180/270° up to 2688×1520) |
| Privacy Masking | 4 areas |
| Audio | 1 audio input + 1 audio output (terminal) Compression: PCM; G.711a; G.711Mu; G.726; G.723 |
| Network Port | RJ-45 (10/100 Base-T) |
|---|---|
| Network Protocols | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P |
| Interoperability | ONVIF (Profile S/G/T/M); CGI |
| Local Storage | Micro SD card (max 512 GB); FTP; SFTP; NAS |
| User/Host / Bandwidth | 20 users (total bandwidth 80 Mbps) |
| Cybersecurity | Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; X.509 cert; syslog; HTTPS; 802.1x; Trusted boot/execution/upgrade; Session security; Security warning |
| Management Software / Browser | Smart PSS Lite; DSS; DMSS; DoLynk Care; IE11+, Chrome 45+, Firefox 46+, Safari 12+, Edge; iOS/Android |
I/O Interfaces & Alarm
| Audio Input / Output | 1 terminal input + 1 terminal output |
|---|---|
| Alarm Input / Output | 1 wet contact input (5 mA 3–5 VDC) + 1 wet contact output (300 mA 12 VDC) |
| Alarm Linkage | :|
| Alarm Event | No SD card; SD card full/error; network/IP conflict; illegal access; motion/tampering; tripwire; intrusion; fast moving; abandoned/missing object; loitering; people gathering; parking; scene changing; audio detection; voltage alarm; external alarm; face detection; security exception; SMD; people counting (area/stay/queue number/time); etc. |
| Power Supply | 12 VDC (±30%) OR PoE (802.3af) |
|---|---|
| Power Consumption | Basic: 4.3 W (DC) / 4.9 W (PoE) Max (AI + WDR + IR): 6.2 W (DC) / 8 W (PoE) |
| Operating Temperature / Humidity | –40 °C to +60 °C (–40 °F to +140 °F) | ≤95% RH (non-condensing) |
| Protection Ratings |
IP68 (weatherproof/submersible), NEMA 4X (anti-corrosion, moderate protection) Explosion-proof: ATEX (TÜV 24 ATEX 9126 X), IECEx (IECEx TUR 24.0026X) |
| Anti-corrosion Level | Moderate Protection – high-grade anti-corrosion, suitable for coastal areas >2 km and acid rain environments. |
| Certifications | CE-LVD (EN62368-1); CE-EMC (2014/30/EU); ATEX; IECEx; UL 50E NEMA Type 4X |
| Casing Material | High-strength aluminum alloy (metal) |
|---|---|
| Product Dimensions | 200.6 mm × 127 mm × 136 mm (7.90" × 5.00" × 5.35") (L×W×H) |
| Net Weight / Gross Weight | 2.1 kg (4.63 lb) / 2.5 kg (5.51 lb) |
